Using The Printer Driver With Ipp - Muratec QUADACCESS MFX-2550 Guide Printer Manual

9
Click [Browse], select the printer driver to install, and click [OK].
For details on the types and locations of the printer drivers to install, refer to
Drivers". (See page 1-2.)
10
Click [Next], and follow the instructions on the screen.
• If the "User Account Control" screen is displayed, click [Continue].
• If the Windows Security screen is displayed, click [Install this driver software anyway].
11
Click [Finish].
12
After the installation is finished, confirm that "Printer" is displayed for the
name of the installed printer driver.
13
Remove the disc from the CD-ROM drive.
Note
If you are using Windows 2000 and you cannot print, SNMP may be enabled.
Follow the procedure below to disable the SNMP settings.
1 Open the "Printers" folder, right-click the printer name without selecting it, and
select [Server Properties].
2 Select the specified port from the "Ports" tab, and click [Configure Port].
3 Deselect "SNMP Status Enabled".

Using the Printer Driver With IPP

Note
• To use the printer driver via IPP, confirm in advance that your network environment
can use the HTTP protocol.
• If the HTTP port number has been changed from the default value of "80", enter the
following URL when performing the installation.
Example) http://xxx.xxx.xxx.xxx:631/ipp (when the HTTP port number has been
changed to "631")
• To specify the printer name, confirm in advance that your network environment can
use DNS.
• When using the printer driver (Muratec MFX-2550) via IPP, you cannot use the
enlarge/reduce function.
1
Insert the disc into the CD-ROM drive of the computer.
2
Click [Start]
The "Printers" screen is displayed.
2-18 Installing From the Add Printer Wizard
 [Control Panel]  [Hardware and Sound]  [Printers].
"Overview of
