Configuring Workgroups Using LCM

5.2 WORKGROUP CONFIGURATION EXAMPLES

Figure 5-1 shows an example of a typical Workgroup configuration. In this
example, two Workgroups are used: Workgroup Alpha and the Default
Workgroup. Workgroup Alpha contains ports 3,5,7 and 9, and the Default
Workgroup contains all ports not contained in Workgroup Alpha.
1. The system creates the Default Workgroup.
NOTES
2. If Workgroups were not defined, all ports are members of the
Default Workgroup.
Workgroup Alpha
Ports 3, 5, 7, 9
In this example, all broadcast, multicast, and unicast packets will be restricted to
the Workgroups.
5-2
Figure 5-1. Traffic Within Workgroups
Workgroup Default
Ports 1, 2, 4, 6, 8, and 10 - 27
