2.5.6 VLAN Command

The VLAN command, when operating in 802.1Q mode, allows you to specify an
IEEE 802.1Q VLAN. You can specify a VLAN ID, and a name to associate with
that ID (optional). If you want to manage this unit on this VLAN you must also
assign an IP Address either here or using the IP address command.
vlan [add PORT-RANGE NAME VLAN-ID [IP ADDR] [[IP MASK]]
[del[ete] PORT-RANGE {NAME |VLAN-ID}]
[res[trict] {add | de[lete]} PORT-RANGE VLAN-ID]
If the command alone is specified, the existing VLANs are displayed. Two types
of VLANs are displayed; the static entries that have been created by this
command, and dynamic entries which have been learned by the switch via
GVRP.
The available range of VLANs in hex is 0x001 to 0xffe.
NOTE
This corresponds to decimal 1 to 4094. Only 32 can be used
at one time on the ELS10-27TX.
ELS10-27>vlan add 5-9 blue 0x025
VLAN-ID NAME
0x001 Default
0x025 Blue
By using the VLAN command, the default VLAN ID on the specified group of
ports for the port will not be changed. Refer to the port command to change the
default VLAN ID for a port.
If the restriction option is specified, the switch will not allow a VLAN to be
established for that ID on the specified group of ports from either a user interface
or GVRP.
There is no support for GVRP with ELS10-27TX Version 1.01.00.
NOTE
GVRP will be supported in a subsequent release.
Enhancements to LCM Commands
TYPE IP Addr
STATIC 10.2.7.225
STATIC 0.0.0.0
IP MASK PORTS
255.255.0.0 1-27
0.0.0.0 5-9
2-11
