4.3 CONFIGURATION ENTRIES

This section provides you with VLAN configuration entries. For instructions on
configuring VLANs, refer to Chapter 3, Configuring VLANs Using SNMP.

4.3.1 Entry (VlanConfigEntry)

This entry allows configuration of specific VLAN entries. Although this is
configured as a table, there is only a single instance. Entries must be referenced
as simple variables.
els10-27VlanConfigEntry OBJECT-TYPE
SYNTAX Els10-27VlanConfigEntry
ACCESS not-accessible
STATUS mandatory
INDEX { els10-27VlanConfigVID }
::= { els10-27VlanConfigTable 1 }
The MIB OBJECT IDENTIFIER for the VlanConfigEntry is:
OID 1.3.6.1.4.1.97.9.20.6.4.1

4.3.1.1 VlanConfigEntry

Els10-27VlanConfigEntry ::= SEQUENCE {
els10-27VlanConfigIndex
INTEGER,
els10-27VlanConfigVID
OCTET STRING,
els10-27VlanConfigPorts
OCTET STRING,
els10-27VlanConfigIP
IPADDRESS,
els10-27VlanConfigIPMask
IPADDRESS,
els10-27VlanConfigName
DisplayString,
els10-27VlanConfigStatus
INTEGER,
els10-27VlanConfigEstablish
INTEGER
}
