Enhancements to LCM Commands

2.4 BASIC LCM COMMANDS

To manage the SmartSTACK Ethernet ELS10-27TX using LCM, you first must
connect the switch to an ASCII terminal or terminal emulator.
To use LCM, begin by pressing the Enter key several times to get the LCM
prompt (ELS10-27>).

2.4.1 Help

Displays the menu of available commands. Help can also be displayed by typing
a question mark (?).
Telnet support allows you to telnet to the device and gain access to LCM. The
device allows 4 sessions. The only password for telnet is the Read-Write
community name for the device and this name allows full access. You are not
allowed to modify passwords via a Telnet session. If an IP address is added or
modified using Telnet, the new address will not take affect until the next reboot.
The Read-Write community name is not used to make modifications to the
configuration. Reading the configuration can be accomplished without
knowledge of the Read-Write community name. There is no support for the
Read-Only community name. Any name other than the Read-Write Community
name will allow for Read-Only access.

2.4.2 Erase

Entering to erase the current SmartSTACK Ethernet ELS10-27TX
erase
configuration returns all parameters to the default values. You will be prompted
to complete the command.
You must type "YES" and reboot the system to implement the
NOTE
change. If only "Y" is entered, the change will not be implemented.

2.4.3 Exit or Logout

This command logs you out of LCM. (The
equivalent to the
2-4
command.)
logout
command is functionally
exit
