VLAN MIB Objects

4.2.2 Operating Mode (VlanOperatingMode)

This object selects the mode of operation (802.1D = 1 or 802.1Q = 2). The switch
can operate as an 802.1d switch, or as an 802.1d switch with IEEE VLAN
capability (802.1Q). A read of this object will return the current operating mode.
Changing the value will not change the operation of the switch
NOTE
until the unit is rebooted.
DEFVAL { ieee8021d }
els10-27VlanOperatingMode OBJECT-TYPE
SYNTAX INTEGER { ieee8021d(1), ieee8021Q(2) }
ACCESS read-write
STATUS mandatory
::= { els10-27VlanBridgeConfig 2 }
The MIB OBJECT IDENTIFIER for accessing the VlanOperatingMode is:
OID 1.3.6.1.4.1.97.9.20.2

4.2.3 Reset (VlanReset)

This MIB object resets a specified bridge. This MIB is not supported in ELS10-
27TX Version 1.01.00.
The MIB OBJECT IDENTIFIER for accessing the VlanReset is:
OID 1.3.6.1.4.1.97.9.20.3
4-2
