This appendix provides information about the following:
For information about...

DFE-Platinum Module Specifications

COM Port Pinout Assignments
Regulatory Compliance
Enterasys Networks reserves the right to change the specifications at any time without notice.
DFE-Platinum Module Specifications
Table A‐1 provides the I/O ports, processors and memory, physical, and environmental module
specifications for the 2G4082‐25.
Table A-1 Specifications for 2G4082-25
Item
Ports
Ports 1 through 24
Network Expansion Module option slot
Processors/Memory
Processor
Dynamic Random Access Memory
(DRAM)
FLASH Memory
Physical
Dimensions
Approximate Weight
Calculated hours for Mean Time
Between Failures (MTBF) for the
2G4082-25
Specification
Twenty-four 10BASE-T/100BASE-TX/1000BASE-T compliant
ports through twenty-four RJ45 connectors.
Supports one optional NEM.
MPC750CX, 400 MHz processor
128 MB
32 MB
46.43 H x 6.05 W x 29.51 D (cm)
18.28 H x 2.38 W x 11.62 D (in.)
Gross: 5.54 kg (12.0 lb) (shipping carton containing one
module)
Net: 4.10 kg (9.0 lb) (one module without packaging)
Refer to the MTBF web site at URL
http://www.enterasys.com/support/mtbf/
Matrix DFE-Platinum Series Installation Guide A-1
A
Specifications
Refer to page...
A-1
A-2
A-2
