Completing the Installation of a New System

The 2G4082‐25 becomes the management module on the Matrix chassis power up. A complete list
of the factory default values are provided in the Enterasys Matrix DFE‐Diamond/Platinum Series
Configuration Guide.
After installing the 2G4082‐25 into the chassis and making the connections to the network,
proceed to "First‐Time Log‐In Using a Console Port Connection" on page 3‐15, to access the
module management startup screen from your PC, terminal, or modem connection.

First-Time Log-In Using a Console Port Connection

Start the Command Line Interface (CLI) from the module's local console port as follows:
1. Connect a terminal to the local console port as described in "Connecting to COM Port for
Local Management" on page
2. At the login prompt, enter one of the following default user names:
–
–
–
3. Press Enter.
4. The Password prompt displays. Leave this string blank and press Enter. The module
information and Matrix prompt displays as shown in Figure
The DFE‐Platinum module is now ready to be configured. For information about setting the IP
address and configuring Telnet settings for remote access to DFE management, refer to the
Enterasys Matrix DFE‐Diamond/Platinum Series Configuration Guide. The CLI commands enable you
to initially set up and perform more involved management configurations.
The Enterasys Matrix DFE‐Diamond/Platinum Series Configuration Guide is available online at:
http://www.enterasys.com/support/manuals
If you require assistance, contact Enterasys Networks using one of the methods described in
"Getting Help" on page xiii.
Note: The DFE-Platinum 2G4082-25 module can be installed in the single-slot of the Matrix N1
chassis, or in any slot of the Matrix E7, Matrix N7, Matrix N5, or Matrix N3, but does not have FTM
connectivity.
When installed in the Matrix E7, Matrix N7, Matrix N5, or Matrix N3, the 2G4082-25 will boot as a
standalone device with no connectivity to other modules in the chassis.
Note: This procedure applies only to initial log-in, and to logging in to a device not yet configured
with administratively-supplied user and password settings.
By default, the Matrix DFE Series device is configured with three user login accounts: ro for Read-
Only access; rw for Read-Write access; and admin for super-user access to all modifiable
parameters. The default password is set to blank (carriage return). For information on changing
these default passwords, refer to the Enterasys Matrix DFE-Diamond/Platinum Series
.
Configuration Guide
ro for Read‐Only access,
rw for Read‐Write access, or
admin for Super User access. (This access level allows Read‐Write access to all modifiable
parameters, including user accounts.)
3‐10. The startup screen, Figure
Matrix DFE-Platinum Series Installation Guide 3-15
Completing the Installation of a New System
3‐11, displays.
3‐11.
