A.6.3 Setup Sensor

For details on this feature, see 7.5 - Setup System - Setup Sensor.

Setup Sensor

SETUP SENSOR
Setup for analog
input points
Select sensor to edit
SENSOR
1=SENSOR_1
2=SENSOR_2
3=SENSOR_3
4=SENSOR_4
5=RETURN TO SETUP MENU
6=RETURN TO MAIN MENU
SELECT A NUMBER:1
>IS THE SENSOR CONNECTED-YES(Y) OR NO(N)?
>[N]
>[]
>CHANGE SENSOR LABEL(8 CHARACTERS MAX).
>[SENSOR_1]
>[]
>CHANGE UNITS LABEL(3 CHARACTERS MAX).
>[DEG]
>[]
>CHANGE 4 mA VALUE(+045.0 TO +096.0).
>[+045.0]
>[]
>CHANGE 20 mA VALUE(+045.0 TO +096.0).
>[+096.0]
>[]
>CHANGE OFFSET VALUE(-999.9 TO +999.9).
>[+000.0]
>[]
>IS SENSOR AN ALARM(AL) OR EVENT(EV)?
>[AL]
>[]
>IS SENSOR ALARM LATCHED-YES(Y) OR NO(N)?
>[Y]
>[]
>CHANGE LOW SETPOINT.
>[-0015.0]
>[]
>CHANGE HIGH SETPOINT.
>[+0015.0]
>[]
>DELAY TIME BEFORE TRIGGER (MM:SS)?
>[00:01]
>[]
VALUE
80.0 DEG
------ DEG
80.0 DEG
79.5 RH
98
Setup Menu
