A.6 S
M
ETUP
ENU
The Setup menu allows the user to configure the AC8—setting up inputs and outputs and an input/
output matrix to trigger actions, the modem and pagers, and system features such as date and time.
This menu also provides a vehicle for manually changing the state of an output to ON or OFF, clear-
ing active alarms and deleting records from the AC8's alarm log, event log and trend logs.
Main Menu
After you connect to the Service Terminal Interface, the Main Menu appears, as shown below.
Main Menu
LIEBERT AC8
VX.XXX.X
LIEBERT CORPORATION COPYRIGHT 2005
ALL RIGHTS RESERVED
MAIN MENU
1=VIEW ACTIVE ALARMS
2=VIEW ALARM LOG
3=VIEW EVENT LOG
4=VIEW TREND LOG
5=VIEW INPUT & SENSOR STATUS
6=VIEW OUTPUT STATUS
7=VIEW PAGER NUMBERS
8=SILENCE ALARM
9=BACKUP LOG FILES
A=VIEW OPERATION STATUS
B=VIEW CONTROL RELAYS STATUS
0=SETUP SYSTEM - LOGIN REQUIRED
SELECT A NUMBER:0
• Choose 0 to access the features illustrated in this section.
Login Menu
The System and Control options require a password to prevent unauthorized users from making
changes to the system. After you enter 0 in the Main Menu above, the Login Menu appears:
Login
YOU MUST LOGIN TO PERFORM
SETUP OR TO MAKE CHANGES
LOGIN WITH 4 CHARACTER
PASSWORD
>****
>INVALID PASSWORD, ENTER AGAIN
>PRESS <ESC> TO EXIT
>
• Enter the password, and the Setup Menu appears, as shown in the following section.
95
