A.6.1 Setup Inputs

For details on this feature, see 7.3 - Setup System - Setup Inputs.

Setup Inputs

SETUP INPUTS
Setup input of device
Select input to edit
INPUT
1=DEVICE_1
2=DEVICE_2
3=DEVICE_3
4=DEVICE_4
5=DEVICE_5
6=DEVICE_6
7=DEVICE_7
8=DEVICE_8
9=RETURN TO SETUP MENU
0=RETURN TO MAIN MENU
SELECT A NUMBER:1
>CHANGE LABEL(8 CHARACTERS MAX).
>[DEVICE_1]
>[]
>IS INPUT NORMALLY OPENED(NO) OR NORMALLY CLOSED(NC)?
>[NO]
>[]
>IS INPUT AN ALARM(AL) OR EVENT(EV)?
>[EV]
>[]
>IS ALARM LATCHED-YES(Y) OR NO(N)?
>[N]
>[]
>DELAY TIME BEFORE TRIGGER (MM:SS)?
>[00:01]
>[]
A.6.2 Setup Common Alarm
For details on this feature, see 7.4 - Setup System - Setup Common Alarm.

Setup Common Alarm

SETUP COMMON ALARM
Select if the common
alarm relay contact
is to reset with
silence alarm
1=SETUP COMMON ALARM
2=RETURN TO SETUP MENU
3=RETURN TO MAIN MENU
SELECT A NUMBER:1
>RESET COMMON ALARM WITH SILENCE-YES(Y) OR NO(N)?
>[N]
>[
DEFINITION
****************************
NO=NORMALLY OPENED
NO-EV-NL-00:01
NC=NORMALLY CLOSED
NO-AL-L -00:01
NC-EV-NL-00:01
EV=EVENT
NO-AL-L -00:01
AL=ALARMABLE
NC-AL-L -00:01
NO-EV-NL-00:01
NL=NOT LATCHED
NO-AL-L -00:01
L =LATCHED
NC-EV-NL-00:01
MIN:SEC=DELAY TIME BEFORE
NOTE:EVENT CANNOT BE LATCHED
****************************
CURRENT
SETTING
INPUT WILL TRIGGER
N
97
