Introducing the PCI-DIO24

This manual explains how to install, configure and use the PCI-DIO24 digital I/O board.
The PCI-DIO24 provides 24 lines of digital I/O. An on-board, industry standard 82C55 programmable
peripheral interface chip provides the 24 digital I/O lines in three eight-bit ports (Port A, Port B, and Port C).
Port C can be further divided into two four-bit ports (Port C-HI and Port C-LO). You can configure each port
independently for either input or output. All 24 I/O lines are accessible through the board's 37-pin connector.
The I/O pins of an 82C55 are bi-directional CMOS TTL level.
82C55 mode 1 or mode 2 operation
This user's guide provides information on I/O configuration of the 82C55 in mode 0. To use the 82C55 in
modes 1 or 2, refer to the 82C55A CMOS Programmable Interface datasheet. This document is available on our
web site at www.mccdaq.com/82C55.

Software features

For information on the features of InstaCal and the other software included with your PCI-DIO24, refer to the
Quick Start Guide that shipped with your device. The Quick Start Guide is also available in PDF at
www.mccdaq.com/PDFmanuals/DAQ-Software-Quick-Start.pdf.
Check www.mccdaq.com/download.htm
under less commonly used operating systems.
for the latest software version or versions of the software supported
