Replacing Hard Disk Drive

The hard disk drive of the Notebook can be removed since it is mounted on a
removable tray. The tray can house either any 2 .5" IDE hard disk drive with a height
of 19mm or less, or any 3.0" IDE hard disk drive with a height of 12.5mm or less.
You should contact your dealer for the proper hard disk case if the other size of hard
disk is used instead. The system BIOS supports dr ives with capacities greater than
528MB through the Logical Block Addressing (LBA) mode. The system setup that is
included with the BIOS can be used to configure the system to accept different drives.
Refer to Chapter 3, WINBIOS Setup for instructions to operate the utility.
Removing
Turn the system power off.
Press the hard disk latch leftward. Holding the latch leftward, pull gently and
firmly the hard disk away from the compartment.
Be careful when disconnecting the cable from the hard disk drive not to bend any
pins or "crimp" the cable.
Inserting
When inserting the hard disk drive back into the Notebook, be sure to firmly seat the
hard disk drive tray into the compartment. You will feel the tray "click" into position
when it is seated properly.
