5. Locate the Memory sockets
6. If there is a module currently installed which needs to be upgraded/replaced
then remove it.
7. Gently pull the two latches (
socket toward the sides of the computer, as indicated in
8. The module (Figure 6 -
1
9. Insert a new module holding it at about a 30° angle and fit the connectors
firmly into the memory slot.
and (Figure 6 -
1 2
1
2
4
3
and in Figure 6 -
3 4
8) will pop-up, and you can remove it.
Upgrading The Computer
7).
7) on the memory
Figure 6 - 7.
Upgrading the System Memory 6 - 11
Contact Warning
Be careful not to touch
the metal pins on the
module's connecting
edge. Even the clean-
est hands have oils
which can attract parti-
cles, and degrade the
module's perfor-
mance.
Figure 6 - 7
Memory Sockets
6
