Upgrading The Computer
Warranty Warning
Please check with your
service representative
before undertaking any
upgrade procedures to
6
find out if this will VOID
your warranty.
Figure 6 - 5
Bay Two Device
Removal

6 - 8 Upgrading the Device in Bay Two

Upgrading the Device in Bay Two
If you need to upgrade or replace the device in Bay Two then follow this pro-
cedure, however take note of the warranty warning on the right.
1. Turn the computer OFF.
2. Place the computer on a clean, stable surface and turn it over.
3. Remove screw (Figure 6 -
1
1
4. Apply gentle, but firm, pressure at point
device out of the computer.
5. Just reverse the removal procedure to install the new device.
5).
2
(Figure 6 - 5) and slide the
2
