User Manual
PCI Modem
QUICK START
This Quick Start describes PCI modem installation for
computers using Windows
Please make sure you have the following: modem,
telephone cord, and software on diskette(s) or CD-
ROM.
Windows 98/Me/2000/XP Users:
You must run the setup software before installing the modem
card. Continue with
Installing the Drivers
Important – If your computer already has an internal
PCI modem installed
You should remove the modem and its drivers now. Your old
modem may interfere with the installation of your new modem.
Please refer to page 6 now.
Installing the Drivers
1 1 1 1
Your computer should be on. Close any running
applications.
Insert the CD-ROM disc that came with your modem into
your CD-ROM drive. If the CD does not start
automatically, double-click My Computer on your
desktop; then double-click the icon for your CD-ROM
drive. If the installation program doesn't begin
immediately, double-click Setup.exe.
2 2 2 2
When the main installation menu opens, click Install
Modem Drivers and then click PCI Drivers.
The installation program runs and automatically copies
driver files to your hard drive. Follow the prompts.
™
98, Me, 2000, or XP.
below.
Advertisement
Table of Contents
Related Manuals for Hayes H08-15531DF
Summary of Contents for Hayes H08-15531DF
-
Page 1: Quick Start
PCI Modem QUICK START This Quick Start describes PCI modem installation for ™ computers using Windows 98, Me, 2000, or XP. Please make sure you have the following: modem, telephone cord, and software on diskette(s) or CD- ROM. Windows 98/Me/2000/XP Users: You must run the setup software before installing the modem card. -
Page 2: Installing The Modem Card
3 3 3 3 Windows 98/Me/2000/XP Users: When asked whether or not you want to restart your computer, select No, I will restart my computer later, click Finish, return to the CD’s main menu, exit, and shut down manually. Continue with Installing the Modem Card, below. - Page 3 5 5 5 5 Slide the modem card firmly into the free PCI slot. PCI slot 16-bit Typical cover ISA slots plate Be sure that the back end of the card (smaller gold finger area) is properly seated into the connector. If you have a tower or mini-tower computer case with a vertical main board, lay the computer down on its side so you can push straight down on the modem card to seat it firmly in its...
-
Page 4: Completing The Installation
Windows 2000 Users: A few seconds after startup, you may see the Digital Signature Not Found dialog box. You can safely ignore this message and click Yes. Continue below with Completing the Installation. Windows XP Users: When the Found New Hardware Wizard dialog box appears, click Next. -
Page 5: Installing The Communications Software
Important—If Your PC Had an Existing Modem You must redirect your application software so that it recognizes your new modem. • America Online Users: From the AOL Welcome screen, click the Setup button; then click Expert Setup. Select the Devices tab and double-click the name of your new modem. •... -
Page 6: Removing A Pci Modem And Its Drivers
Removing a PCI Modem and Its Drivers You should follow these instructions if your computer already has a PCI modem installed, and you want to replace it with your new modem. 1 1 1 1 From the desktop, open the Control Panel, and then click Add or Remove Programs. -
Page 7: Regulatory Information
Regulatory Information U.S. FCC Part 68 Statement This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. The unit bears a label on the back which contains among other information a product identifier in the format US:AAAEQ##TXXXX. If requested, this number must be provided to the telephone company. - Page 8 FCC Part 15 Emissions Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 9 quelconque de dispositifs, à la seule condition que la somme d'indices d'équivalence de la sonnerie de tous les dispositifs n'excède pas 5. Electrostatic Discharge Statement The unit may require resetting after a severe electrostatic discharge event. Safety Notices CAUTION: To reduce the risk of fire, if you do not use the supplied phone cord, use only No.
-
Page 10: Declaration Of Conformity
Declaration of Conformity Declaration of Conformity Overensstemmelseserklæring Conformiteitsverklaring van de EU Déclaration de conformité Konformitätserklärung ∆ήλωση Συµµόρφωσης Dichiarazione di conformità Deklaracja zgodności Declaração de Conformidade Declaración de conformidad Konformitetsdeklaration Cam kết về sự tuân thủ ở Châu Âu Type/Typ/Μάρκα/Tipo/Türü/Kiểu mẫu Series 1055 The manufacturer declares under sole responsibility that this equipment is compliant to Directive 1999/5/EC via the following. - Page 11 NOTICE This document contains proprietary information protected by copyright, and this Quick Start Guide and all the accompanying hardware, software, and documentation are copyrighted. All rights are reserved. No part of this document may be photocopied or reproduced by mechanical, electronic, or other means in any form. The manufacturer does not warrant that the hardware will work properly in all environments and applications, and makes no warranty and representation, either implied or expressed, with respect to the quality,...
- Page 12 0826-B 27422 ©2006...
