9 Specifications

This appendix provides the operating conditions (environmental requirements), hardware specifications,
physical requirements, power requirements, and video resolutions of the HP Server tc2110. The system board
layout and its connectors are also provided. See Figure 9-1.
The specifications listed may vary if you install a mass storage device in your server that has more stringent
environmental limits. Ensure the operating environment for your server is suitable for all of the mass storage
devices being used.

Environmental

Temperature
Operating
Non-operating
Humidity
Operating
Non-operating
Altitude
Operating
Non-operating
Thermal Output
Maximum Operating
Accoustic Emissions
Operating

Weight and Dimensions

Weight
Height
Width
Depth

Power Supply Specifications

Parameter
Input Type
Input – Maximum Range
Operating Current
In-rush Current
5° to 35° C (41° to 95° F) at 10,000 ft
-40° to + 65° C (-40° to + 149 F°)
20 % to 80 % relative humidity, non-condensing
5% to 95% relative humidity, non-condensing
-30 to 3,045 m (~ 10,000 ft)
-30 to 12,180 m (~ 40,000 ft)
1312 BTU/hr
LpA: <38 dBA
Basic configuration approx. 14.8 kg. (32.5 lbs) – excludes keyboard and monitor.
Fully loaded approx. 22.5 kg. (50 lbs) – excludes keyboard and monitor.
476mm (18.7 inches)
205mm (8.08 inches)
467mm (18.3 inches)
Characteristics
Manual voltage selection
100 to 127 VAC @ 50/60 Hz
200 to 240 VAC @ 50/60 Hz
100 to 127 VAC: 7.0 A
200 to 240 VAC: 3.5 A
90 A (cold) 120 A (warm)
105
