Receive Port
The Receive Port list box speciÞes the port on which packets from the speciÞed
static address must be received in order for the static database entry to apply. If
All is selected, the entry will be applied to packets forwarded to any port.
Forward To Ports
The Forward To Ports list box speciÞes the ports to which packets with the
speciÞed source address received on the speciÞed ports will be forwarded. The
port or ports selected in this list will be displayed in the Filtering Database
window as the Destination Port.
To change an entry:
1. Click mouse button 1 on the port in the Receive Port list box that you want to
2. Click mouse button 1 on any port or ports in the Forward To Ports list that
3. Click mouse button 1 on the Status button and choose one of the following:
4. After you set the entry's status, click mouse button 1 on the Apply button.

Deleting a Static Table Entry

To delete a Static Table entry:
1. In the Filtering Database window, click mouse button 1 in the appropriate
2. Select the entry you want to delete by clicking it with mouse button 1.
3. Click on the Delete button.

Finding a Filtering Database MAC Address

To Þnd a source address in the Filtering Database:
1. In the Filtering Database window, click on the
The Filtering Database Window
specify as the receive port for the entry in the Static Address field (remember
that if All is selected, the entry will be applied to packets received on any
port).
you want to be displayed in the Filtering Database window as the destination
port.
permanent—The entry won't be aged out or deleted on reset.
deleteOnReset—The entry will deleted when the bridge is reset.
deleteOnTimeout—The entry is subject to the Aging timer.
selection box to display the Static database.
Find MAC Address window.
or
CSX Bridge View
button to open the
