About the CSX400

The CSX400 supports multiple LAN options through two Ethernet ports. These
ports can be conÞgured with any combination of the following Cabletron EPIM
connections:
EPIM-A
EPIM-C
EPIM-T
EPIM-F1
EPIM-F2
EPIM-F3
For more information on these EPIMs, consult your hardware documentation.
The CSX400 also consists of two WAN interfaces, which can currently be
conÞgured with any combination of Cabletron WPIMs, which are described in
CSX WPIMs

Applications

You can use the following SPMA applications to manage your CSX400 device:
Bridge View
The Bridge View application is described in Chapter 3, CSX Bridge View. The
Bridge View allows you to conÞgure bridging and Þltering parameters, and to
view statistics on your CSX400 bridge.
Router Configuration
The Advanced and Basic Router ConÞguration applications are both detailed in
your SPMA Routing Services ConÞguration Guide. Through Basic ConÞguration
you can set and view routing parameters on each port. With Advanced
ConÞguration you can conÞgure static routes and secondary addresses, monitor
and control routing tables, and apply network security measures using access
control lists.
WAN Configuration
Chapter 4, CSX WAN ConÞguration, describes this application in detail. With the
CSX200Õs WAN ConÞguration window, you can set wide-area protocols and
conÞgure those settings, as well as conÞgure the WPIM installed on your device.
RMON Configuration
The RMON application must be purchased separately, and is documented in its
own UserÕs Guide.
About the CSX400
Female AUI interface with DB-15 connector
10Base-2 coaxial port, BNC connectors
10Base-T twisted pair port with RJ45 connector
10BaseFL multi-mode Þber port with SMA connectors
10Base-FL multi-mode Þber port with ST connectors
802.3 single-mode Þber port with ST connectors
on page 2-4.
Device Configuration
2-3
