CSX Bridge View
IP Address
The deviceÕs Internet Protocol address. You cannot change the IP address from
SPMA. For multi-interface devices, this will be the IP used to deÞne the device
icon (if you are using a management platform) or the IP used to launch the
application (if you are running in stand-alone mode).
MAC Address
The deviceÕs factory-set MAC hardware address.
Clicking on the Device button displays the Device menu. The Device menu lets
you perform the following (depending on what is supported by your device):
¥
¥
¥
¥
¥
¥
¥
It is possible you may also see a menu selection for SmartTrunk. Please be aware that the
SmartTrunking feature is not supported by the CSX200/400.
NOTE
If you need to call CabletronÕs Global Call Center about a problem with the Bridge
View, youÕll need the information provided in the Information window:
3-6
Open the Bridge Status window.
Display a summary of bridge statistics.
Open the Filtering Database window.
Open the Find MAC Address window.
Open the Special Database window.
Open the Spanning Tree Protocol window.
Open the Polling Intervals window.
Figure 3-2. Bridge Information Window
Bridge firmware
revision
SPMA Bridge
View version
Accessing the Bridge Traffic View Window
