Reference Part
1 Paper guide
2 Paper support (ASF)
3 Extractable cover
of exposure bed
4 Front panel
5 Front hatch
6 Paper tray
7 Exposure bed
8 Scanning unit
9 Power connector
10 High speed USB
interface
11 Cartridge carrier
12 Front panel USB
interface
4 CHAPTER 1
Description
Guides the paper being fed into the printer.
Supports the loaded paper.
Cover of the scanner. Can be removed to scan bulky documents
(such as books).
Used to switch the printer ON and OFF, and to control print, copy
and scan operations.
Gives access to the compartment containing the print cartridges.
Collects the printed paper as it is ejected from the printer.
Surface on which to position the document or photo to be copied
or scanned, face down. See "Positioning the document on the
Exposure Bed".
Unit containing exposure bed on which to place original.
Connect the power cable of the external universal power supply
unit, furnished with the product, to the printer.
Then connect the other end of the external power supply unit
with the mains cable to a grounded electrical outlet.
note: First of all, connect the cable to the printer, and then to the
outlet.
Using the USB cable to be used for connecting the computer (not
included), plug one end into the printer and the other end into
the USB port on the computer.
Supports two ink cartridges. The colour cartridge is installed on
the right while the black cartridge (or photographic cartridge, sold
separately) is installed on the left.
To replace ink cartridges, see "Replacing Ink Cartridges".
Connects the USB cable of the digital camera, a USB memory
(Mass Storage).
