Lucent Technologies PARTNER Advanced Communications System System Planner Manual page 34

Template Instructions
•
If desired, write in line number, pool access code
•
If desired, write in Line Ringing (Imm, Del, or No) from Form B2
•
If desired, write in Line Access Restriction or Pool Access Restriction
(Out, In, or No) from Form B2
† Available with ACS R2.0 or later only.
Intercom Intercom
* In Hybrid mode only, if pool 880 is assigned, these two buttons are associated with this pool.
(ACS R2.0 or later only)
Specify Automatic Line Selection: ________________________________________________________________
Identify extensions programmed as shown: ___________________________________________________
Make as many copies as you need. Use template and/or checklist. For additional instructions, see pages 8 through 13.
† , dial code feature, or auto dial number
†
Ext.
Form C6: MLS-18D Phone
Also write in extension or group number
Automatic System Answer Button {#111}
Direct Extension Dial Button {#113}
SAMPLE
Night Service Button {#503}
Outgoing Call Restriction Button {#114}
04
Wake Up Service Button {#115}
DEL
Caller ID Call Log (F 23)
IN
Caller ID Inspect (F 17)
Caller ID Name Display (F 16)
Do Not Disturb (F 01)
Privacy (F 07)
VMS Cover (F 15)
Voice Interrupt on Busy Talk-Back (F 18)
Account Code Entry (F 12)
Background Music (F 19)
Call Coverage (F 20 XX XX)
Call Forwarding/Call Follow-Me (F 11 XX XX)
Call Park (I XX)
Call Pickup (I 6 XX)
Conference Drop (F 06)
Contact Closure 1 (F 41)
Contact Closure 2 (F 42)
Direct Line Pickup-Active Line (I 68)
Direct Line Pickup-Idle Line (I 8)
Exclusive Hold (F 02)
Fax Management (I XX)
Group Calling-Ring/Page (I 7 G or I *7 G)
Group Hunt-Ring/Signal (I 77 G or I *77 G)
Group Pickup (I 66 G)
Intercom Autodial (I XX or I *XX)
Last Number Redial (F 05)
Loudspeaker Paging (I 70)
Manual Signaling (F 13 XX or F 13 *XX)
Message Light Off (F 10 XX)
Message Light On (F 09 XX)
Recall (F 03)
Save Number Redial (F 04)
Simultaneous Paging (I * 70)
Station Lock (F 21)
Touch-Tone Enable (F 08)
Voice Mail Messages Button (I 777)
Voice Mailbox Transfer (F 14)
Check Desired Features
6 ASA
6 DXD
NightSvc
1 OCR
Wake
6 Calls
ID-Inspect
ID-Name
DND
Priv
VMSCover
VIOB
ACE
2
2 Music
2,4 ,6 Cover-XX XX
CF-XX XX
2,4
Park
3
Pickup-XX
Drop
CC1
2
CC2
2
DLPA
DLPI
ExHold
FAX-XX
2
GCall-g
Hunt-g
P/U Grp-g
Ext-XX
2
LNR
Loudspk
2 MS-XX
5 MsgOff-XX
5 MsgOn-XX
Recall
SNR
SPage
Lock
2
TT-EN
VMMsgs-777
VMBox
PAGE
6 of 8
1. Requires Auto
Dial button for
each extension.
2. Button with
lights is
recommended,
but not required.
3. Extension
number can be
programmed as
Auto Dial
button.
4. You can
program the
origination
extension only
or both the
origination and
destination
extension.
5. You can
program the
extension
number.
6. Available with
ACS R2.0 or
later only.
F = Feature button
G = Group
I = Left Intercom
button
XX = Extension
