Chapter 9
where
nodename
Manager port, port 8081 by default.
NOTE
Traffic Manager displays the Monitor tab (shown below).

Using Monitor mode

In Monitor mode, Traffic Manager displays a series of buttons on the Monitor tab. Each button represents a
group of statistics. Click on a button to view its statistics. Each button is described briefly below.
NOTE
The Dashboard button
Click the Dashboard button to see a concise view of your Traffic Server system, displaying all cluster nodes
by name and tracking essential statistics for each node. If you want to display detailed information about a
particular node, you can click the node's name on the Dashboard, and then click on one of the other buttons
on the Monitor tab.
is the name of the web cache appliance and
Use the SSL command to reach Traffic Manager only if you have restricted
https
access to Traffic Manager via SSL connections; otherwise, use the standard
command.
All the statistics displayed in Monitor mode are described in detail in
Traffic Manager Statistics.
is the number assigned to Traffic
adminport
Click a button to
display a page
listing statistics
you can view
Click this button to
display a description of
the statistics
Shows the current user logged
on to Traffic Manager
Monitoring Traffic
http
Appendix A‚
64
