Appendix A
Statistic
Query Messages
Received
Remote Query Hits
Remote Query Misses
Successful Response
Messages Sent to Peers
Router's IP address
Router Status
My IP address
Percentage of traffic
directed to this node
Number of heartbeats
received
Enabled
Leader's IP address
Number of active nodes
Security Enabled
Multicast Enabled
Multicast Address
Multicast TTL
HTTP
NNTP
RTSP
PNA
My IP
Number of buckets
assigned to this node
Service Id
Leader's IP
Description
Queries Originating From ICP Peers
The number of ICP query messages received from remote ICP peers (siblings
and parents).
The number of successful cache lookups in response to queries from ICP peers.
The number of unsuccessful cache lookups in response to queries from ICP
peers.
The number of successful ICP messages written in response to ICP queries from
remote ICP peers.
WCCP 1.0 Router Statistics
The IP address of the WCCP router.
Indicates if the WCCP router is running (UP) or not (DOWN).
WCCP 1.0 Node Statistics
The IP address of this Traffic Server node.
The percentage of port 80 traffic directed toward this Traffic Server node.
The WCCP router sends a heartbeat message to this node every 10 seconds. A
heartbeat message is a short message that indicates to the recipient, "I am up
and running." This value is the cumulative number of heartbeats received from
the router.
WCCP 1.0 Protocol Statistics
Indicates if WCCP is enabled on this node.
The IP address of the leader node.
The number of active nodes in the WCCP cache farm.
WCCP 2.0 Configuration Information
Indicates if WCCP security is enabled.
Indicates if multicast mode is enabled.
The IP multicast address (if multicast mode is enabled).
The multicast Time To Live value specifies how many hops the router is from
the cache.
WCCP 2.0 Services Information
Indicates if transparent redirection of HTTP traffic is enabled.
Indicates if transparent redirection of NNTP traffic is enabled.
Indicates if transparent redirection of RTSP traffic is enabled (Media-IXT
option).
Indicates if transparent redirection of PNA traffic is enabled (Media-IXT
option).
WCCP 2.0 HTTP Statistics
The IP address of the Traffic Server receiving HTTP traffic from a WCCP
router.
The number of buckets assigned to this Traffic Server node by the WCCP
router.
The number that identifies the protocol in the router command. 0 is used for
HTTP.
The IP address of the leader node in the WCCP cache farm.
Traffic Manager Statistics
