Egress Shaping Rate
Enable Egress Shaping Rate — Enables setting Egress Shaping
■
Rates.
Committed Information Rate (CIR) — Defines the CIR for the
■
interface. The field options include 128, 1024, 5056, 10048, 50048,
100032 and 500032 kbits per second.
When using the command line interface, the field range is
64-100,000 kbits per second for Fast Ethernet ports, and
64-1,000,000 kbits per second for Gigabit Ethernet ports
at a resolution of 64 kbits per seconds.
Committed Burst Size (CBS) — Defines the CBS for the interface.
■
The field options include 64, 128, 512, 1024, 2048, and 4096 kbits.
Rate limiting is based on a token bucket, where bucket depth (that is,
the maximum burst before the bucket overflows) is specified by the
CBS, and the average rate tokens at which are removed from the
bucket is specified by the CIR.
Select ports — Selects the ports to be configured.
■
2 Select the ports to be configured.
3 Define the fields.
4 Click
and the device is updated.
. The bandwidth is defined for the selected ports,
