1 securing clip
2 tab
3 slot
4 retention base
9. Lower the airflow shroud over the heat sink.
10. Reconnect the cooling fan power cable to the FAN connector on the
11. Reconnect the power cable to the 12VPOWER connector on the
12. Close the computer cover.
NOTICE:
To connect a network cable, first plug the cable into the network wall jack and then plug it into the computer.
13. Connect your computer and devices to electrical outlets, and turn them on.
After you open and close the cover, the chassis intrusion detector, if installed and enabled, causes the following message to appear on the screen at
the next computer start-up:
ALERT! Cover was previously removed.
14.
Reset the chassis intrusion detector
NOTE:
If an admin password has been assigned by someone else, contact your network administrator for information on resetting the chassis intrusion
detector.
Back to Contents Page
system
system
by changing Chassis Intrusion to On or On-Silent.
board.
board.
