Figure 26
VA 7100 Array Controller LEDs
Table 8 HOST FC LEDs Status Indications (See Figure 26)
HOST FC HOST FC
GBIC Active GBIC Fault
(Green) (Amber)
Off
On
Off
Off Flashing
Figure 27 VA 7400 Array Controller LEDs
Table 9 DISK FC & HOST FC LED Status Indications (See Figure 27)
DISK FC
Off Unit not under power
On Valid Fibre Channel link to disk enclosure.
HOST FC
Off Unit not under power
On Valid Fibre Channel link to host.
80 Troubleshooting
Off GBIC not under power
Off GBIC installed and operating normally.
On GBIC fault; GBIC not able to generate Transmit signal.
GBIC fault; GBIC has lost Receive signal.
Indication
or
disk enclosure (backend) FC link down.
or
host (frontend) FC link down.
Indication
or or
link down GBIC not installed.
