Array Controller Filler Panels

Removing an Array Controller Filler Panel
Caution Do not operate the array for more than 5 minutes with an array
controller or filler panel removed. Either an array controller or
filler panel must be installed in the slot to maintain proper
airflow.
1 Loosen the cam lever screws
screwdriver.
2 Pull out both cam levers (2) at the same time.
3 Pull the array controller filler panel (3) out of the slot.
Installing an Array Controller Filler Panel
1 Pull out both cam levers
2 Push the array controller filler panel (3) firmly into the slot.
3 Push in both cam levers at the same time.
4 Tighten the cam lever screws
(Figure 45, 1) with a T-10 driver or flat-blade
(Figure 45, 2) at the same time.
(Figure 45, 1).
