Caution The array controller can be damaged by electrostatic discharge.
Use the ESD kit provided when removing and installing an array
controller.
To prevent data loss, it is recommended that a full backup be
performed before removing an array controller.
Do not operate the array for more than 5 minutes with an array
controller or filler panel removed. Either an array controller or
filler panel must be installed to maintain proper airflow in the
controller enclosure. Use the foam in the replacement array
controller packaging to temporarily plug the empty slot.
1 Perform any necessary prepatory steps indicated in
2 VA 7100: Remove the fiber optic cable from the GBIC (see
VA 7110/7400/7410: Remove the fiber optic cables from the DISK FC
and HOST FC connectors (see
3 VA 7100 only: Remove the GBIC (see
4 VA 7100: Slide the latch
VA 7110/7400/7410: Loosen the cam lever screw
10 driver or flat-blade screwdriver.
5 VA 7100: Press down the lock
VA 7110/7400/7410: Pull out the cam lever
WARNING A hot surface is located on the underside of the array controller
by the middle of the right-hand edge (facing the rear panel). To
avoid burn injury, only touch the edges of the array controller.
Do not touch the underside.
Caution When the cam lever is pulled out, an early warning switch is
activated which suspends mirroring between dual controllers
and terminates all I/Os to the controllers.
6 Grasp the cam lever and slide the array controller out 4 inches (10 cm)
(Figure 43 or Figure 44).
7 Grasp the edges of the array controller with both hands and pull it out of
the slot.
8 If the array controller was removed for a DIMM failure :
Go to "Installing an Array Controller" on page
Figure 40).
Figure 39, 3).
(Figure 43, 1) all the way to the left.
(Figure 43, 2) and pull out the cam lever (3).
(Figure
110.
Servicing & Upgrading 109
Figure 42.
Figure 39).
(Figure 44, 1) with a T-
44, 2).
