HP StorageWorks 7110 - Virtual Array Service Manual page 118

Figure 46
Removing & Installing an Array Controller Battery
5
4
118 Servicing & Upgrading
2
Installing an Array Controller Battery
1 Seat the battery connector
2 Lay the battery (Figure
bracket (5).
3 Place the battery clamp
4 Slide the battery clamp forward so that the front tabs
positioned under the bulkhead tabs (5).
5 Tighten the battery clamp screw
6 Replace the array controller card. See
page 110.
Note If the array controller battery was replaced on a single array
controller, wait for the battery to charge before resuming I/Os.
3
(Figure 47, 1) on the battery terminal (2).
47, 3) on the foam pad (4) and in the battery
(Figure 46, 2) on the battery (3).
(Figure 46, 1) with a T-20 driver.
"Installing an Array Controller" on
1
(Figure 46, 4) are
