HP StorageWorks 7110 - Virtual Array Service Manual page 20

Figure 3 VA 7100 Controller Enclosure (D)
1
2
3
1 - Power/Standby Switch
2 - System LEDs
3 - Disk Drive 1 (of 15) - M/D1*
4 - Disk Drive LEDs
5 - Disk Drive Slot No. 1 (of 15)
6 - Front ESD Ground Receptacle
7 - Array Controller 1 - M/C1*
8 - HOST FC Connector - M/C1.H1*
9 - HOST FC LEDs
20 Product Overview
5
4
6
10 - Array Controller LEDs
11 - RS-232 Connector
12 - Array Controller 2 - M/C2*
13 - AC Power Connector
14 - Power Module 1 - M/P1*
15 - Power Module LEDs
16 - Power Module 2 - M/P2*
17 - Rear ESD Ground Receptacle
*Reference designator used in CommandView SDM
14
13
15
16
7
8
9
10
11
12
17
