Table 29
Controller & Disk Enclosures Electrical Specifications
Electrical
Controller Enclosure
Parameter
Voltage
(Auto-Ranging)
Current
6.85 A @ 100 Vac;
(Maximum)*
5.71 A @ 120 Vac;
3.43 A @ 200 Vac;
2.98 A @ 230 Vac
Frequency
Inrush Current
(Peak)
Power
Consumption
Heat
Dissipation
VA
Rating
100-127 Vac;
200-240 Vac
50/60 Hz
36 A
670 W
2288 BTU/hr
685 VA
*Current rating is with 2 inputs
Disk Enclosure
100-127 Vac;
200-240 Vac
4.8 A @ 100 Vac;
4.0 A @ 120 Vac;
2.3 A @ 200 Vac;
2.1 A @ 230 Vac
50/60 Hz
17.5 A
500 W
1611 BTU/hr
500 VA
Specifications & Regulatory Statements 141
