SMX_SAStorageCapabilities

4-3-30
SMX_SAStorageCapabilities implements the HPSA_StorageCapabilities class and represents the
possible capabilities of a Storage Pool.
Table 4-31
Class: SMX_SAStorageCapabilities (CIM_StorageCapabilities)
Property name
ElementName
InstanceID
DataRedundancyDefault
DataRedundancyMax
DataRedundancyMin
DeltaReservationDefault
DeltaReservationMax
DeltaReservationMin
ElementType
NoSinglePointOfFailure
NoSinglePointOfFailureDefault
PackageRedundancyDefault
Property implementation
CIM_ManagedElement
For Primodial Pools: Controller name and location
Examples:
•
Smart Array in Slot=3, for internal
•
Smart Array Embedded Contoller=7 for embedded
controller where 7 is the internal identifier for the
embedded controller
For Concrete Pools: Controller name and
location:Array identifier
Examples:
•
Smart Array in Slot=3: Array – 0, for internal
•
Smart Array Embedded Controller=7: Array - 0" for
embedded controller where 7 is the internal
identifier for the embedded controller
CIM_Capabilities
Key: Opaque key
CIM_StorageCapabilities
1—When number of drives is an odd number)
2—When number of drives is an even number (For
example, pool can be configured for mirroring.)
1—When number of drives is an odd number
2—When number of drives is an even number (For
example, Pool can be configured for mirroring.)
1
0
0
0
5 (Storage Pool)
True—When number of drives > 1 (For example, pool
can be configured for redundancy.)
False—When number of drives <= 1
True—When number of drives > 1 (For example, pool
can be configured for redundancy.)
False—When number of drives <= 1
0 (When number of drives <= 1)
1 (When number of drives = 2 or 3)
2 (When number of drives > 3)
Smart Array 73
