Table 6-22
Class: SMX_SASStorageCapabilities (CIM_StorageCapabilities)
Property name
NoSinglePointOfFailure
NoSinglePointOfFailureDefault
PackageRedundancyDefault
PackageRedundancyMax
PackageRedundancyMin

SMX_SASProduct

6-1-23
SMX_SASProduct represents the marketing information for the HBA.
Table 6-23
Class: SMX_SASProduct (CIM_Product)
Property name
ElementName
IdentifyingNumber
Name
Vendor
Version

SMX_SASDriveCage

6-1-24
SMX_SASDriveCage represents the drive cage assembly and back plane within a storage enclosure.
There can be multiple instances within a duplexed enclosure.
Property implementation
•
True—When number of drives > 1 (For example,
Pool can be configured for redundancy.)
•
False—When number of drives = 1 or Pool is
NonRAID
•
True—When number of drives > 1 (For example,
Pool can be configured for redundancy.)
•
False—When number of drives = 1 or Pool is
NonRAID
•
0 (When Pool is NonRAID)
•
1 (When number of drives = 1)
•
2 (When number of drives > 1)
•
0 (When Pool is NonRAID)
•
1 (When number of drives = 1)
•
2 (When number of drives > 1)
0
SMX_SASStorageCapabilities
Property implementation
CIM_ManagedElement
Controller name and location
For example, HP 8 INT Port SAS/SATA HBA in Slot 3,
for internal
CIM_Product
Opaque key
String representing the Marketing Name
HP
Firmware version of HBA
SMX_SASProduct
SMX_SAS HBA Provider 175
