PCI Device Provider

3

Overview

3-1
This provider implements the profiles listed to support PCI devices installed in HP servers.
The following table details the profiles implemented and files installed by this provider.
Table 3-1
Overview
Implemented Profiles

Use Cases

3-2
See DMTF PCI Device Profile for Use Cases.

Class Implementations

3-3
The following classes and properties are implemented as specified in the following tables for HP
Server platforms where available. The classes below describe PCI Device.

SMX_PCIDevice

3-3-1
SMX_PCIDevice is used to model PCI devices on HP Servers. There is an instance of this class for each
logical PCI device present in the system.
Table 3-2
Class: SMX_PCIDevice
Property name
Caption
Description
ElementName
Name
•
DMTF: PCI Device Profile (DSP1075) 1.0.0a
09/2007
•
DMTF: Physical Asset Profile
•
HP: Location Profile 1.0
Property implementation
CIM_ManagedElement
A user-friendly description for this PCI device provided
by the operating system
A user-friendly description for this PCI device provided
by the operating system
A hardware ID for this PCI device provided by the
operating system
CIM_ManagedSystemElement
A hardware ID for this PCI device provided by the
operating system
CIM_LogicalDevice
PCI Device Provider 38
