Illustrated Parts List - HP StorageWorks 1510i - Modular Smart Array Service Manual

1 Illustrated parts list

This section provides an illustrated parts breakdown and spare parts list for the HP StorageWorks 1510i
Modular Smart Array (MSA1510i).
Item Description
Standard shipping configuration items:
1
Power supply modules
2 SCSI I/O module
3
Fan modules
2–Port Ethernet iSCSI
4
module
Chassis with
5
backplane
6
MSA Chassis bezel
Service replacement Additional/optional
module part number module part number
349800–001 /
n/a
406442–001
70–41213–S1 /
AA988A
70–41213–T1
349798–001
n/a
417788–001 AD538–04001
70–4121 1–S1 /
n/a
70/4121 1–T1
70–41220–S1
n/a
1510i Modular Smart Array maintenance and service guide
Customer Self Repair
Mandatory
Optional
Mandatory
Optional
Optional
Mandatory
1 1
