A Control Panel Description

Table A-1 describes each item on the control panel shown in Figure A-1:

Hard Disk Activity Light

Yellow = Embedded SCSI

or IDE bus active

Power-On Light

Green = Power is on

Power Button

Reset Button

Keyboard Lock Light

Yellow = Keyboard

is locked

Figure A-1. Control Panel Description
