Chapter 4
Table 4-1 lists the possible settings for each switch. Always set switches 1, 2, and
6 to Off.
Table 4-1. Hot-Swap Cage Switch Settings
Switch Function
2
1 I C Bus Setting
2
2 I C Bus Setting
3 High/Low Addresses
Sets SCSI IDs to upper or
lower eight addresses
Set to Off if not using Fast-
Wide (68 pin) SCSI
4 SCSI Address Zero
Determines SCSI ID of shelf 2
(middle shelf) in hot-swap
cage.
5 Remote Start
Determines control of the hot
swap disk module power-on
sequence.
6 Reserved
22
Configuring Mass Storage
Setting
Always set to Off
Always set to Off
On Sets drives to upper eight SCSI
addresses.
Off Sets drives to lower eight SCSI
addresses.
See Table 4-2 for a description of SCSI
address settings.
On Sets shelf 2 to SCSI ID 0.
Off Sets shelf 2 to SCSI ID 2.
See Table 4-2 for a description of SCSI
address settings.
On Internal control: cage is set to
delayed start. Recommended
setting.
Always set to Off
