  • Page 1: Hp Netserver Ld Pro, User Guide

    HP NetServer LD Pro User Guide HP Part Number D4948-90001 Printed in December 1996...

  • Page 2: Audience Assumptions

    Hewlett-Packard assumes no responsibility for the use or reliability of its software on equipment that is not furnished by Hewlett-Packard.

  • Page 3: Table Of Contents

    Contents 1 Installation Overview ..................1 Verify Contents ....................1 View the Readme File ..................1 Remove the Cover..................2 Install Additional Memory ................3 Install Additional EISA Boards and PCI Boards ..........4 Install Additional Mass Storage Devices............5 Configure the HP NetServer and Install Additional ISA Boards.......5 2 HP NetServer Navigator ................7 Contents of the HP NetServer Navigator CD-ROM.........7 Readme File ....................7...

  • Page 4: Table Of Contents

    5 Installing UPS Software ................25 Before Installing UPS Software ..............25 UPS Installation for Microsoft Windows NT ..........25 To Install the UPS Software on the HP NetServer........26 To Install the UPS User Interface on a Local Client PC ......26 To Install the UPS Manager Application ...........27 UPS Installation for Novell NetWare ............28 To Install the UPS Software on the HP NetServer........29 To Install the User Interface on a Local Client PC ........30...

  • Page 5: Table Of Contents

    9 Warranty and Software License..............49 Hardware Product Limited Warranty.............49 Software Product Limited Warranty..............49 Hewlett-Packard Utility Software ..............49 Third-Party Software Products ..............50 Hardware Accessories Limited Warranty ............50 Hewlett-Packard Hardware Accessories ...........50 Third-Party Hardware Products ..............51 Pre-Failure Warranty..................51 Limitation of Warranty..................51 Limitation of Liability and Remedies............52 Customer Responsibilities ................52...

  • Page 6: Table Of Contents

    Radio Frequency Emissions Warning for Accessories ......73 Declaration of Conformity ................74 Notice for Finland: Laser Safety Statement ..........75 Notice for Germany..................75 Noise Declaration and Ergonomics............75 Laser Safety Statement................75 Notice for Japan...................76 VCCI Statement..................76 Power Line Harmonics ................77 Notice for Korea: RFI Statement ..............77 Mexico: Hardware Warranty Statement............77 Notice for U.K.: General Approval ..............79 Index .......................81...

  • Page 7: Installation Overview, Verify Contents, View The Readme File

    1 Installation Overview This chapter contains simplified setup information about your HP NetServer LD Pro. For complete setup instructions, consult the HP NetServer LD Pro Road Map (English only). Verify Contents Unpack and verify the contents of the shipping box against the Contents Checklist included with your NetServer.

  • Page 8: Remove The Cover

    Chapter 1 Installation Overview Remove the Cover If you are installing options, you will need to remove the cover. WARNING Before removing the cover, always disconnect the power cord and unplug telephone cables. Disconnect telephone cables to avoid exposure to shock hazard from telephone ringing voltages.

  • Page 9: Install Additional Memory

    Chapter 1 Installation Overview Install Additional Memory Use HP DIMMs listed on the Technical Information Label on top of the chassis. 1. Remove the processor board. 2. Align the notches on the DIMM with the keys on the socket. 3. Insert the DIMM until the retaining clips snap into place. 4.

  • Page 10: Install Additional Eisa Boards And Pci Boards

    Chapter 1 Installation Overview Install Additional EISA Boards and PCI Boards NOTE Do not install ISA boards until instructed by the Configuration Assistant program in "Configure the HP NetServer and Install Additional ISA Boards", below. Technical Information Label Board Retainer Figure 1-3.

  • Page 11: Install Additional Mass Storage Devices, Configure The Hp Netserver And Install Additional Isa Boards

    Chapter 1 Installation Overview Boards can be identified by the shape of their connectors: EISA Figure 1-4. Connector identification Install Additional Mass Storage Devices NOTE In certain configurations, if you are installing an IDE drive or SCSI devices you will need additional cables or adapters. For configuration information, see the Technical Information Label on the side of the chassis, or Information Assistant on the HP Navigator CD-ROM.

  • Page 12

    Chapter 1 Installation Overview 3. If the HP NetServer Navigator CD-ROM is not loaded in the CD-ROM drive, insert the CD-ROM into the CD-ROM drive now and press the Reset button on the front of the server. The HP NetServer automatically boots from the HP NetServer Navigator CD-ROM.

  • Page 13: Hp Netserver Navigator, Contents Of The Hp Netserver Navigator Cd-rom, Readme File

    2 HP NetServer Navigator Contents of the HP NetServer Navigator CD-ROM The HP NetServer Navigator CD-ROM Main Menu directs you to modules where you can perform configuration tasks or access online system documentation. The following is a description of the contents of the CD-ROM as accessed from the Main Menu.

  • Page 14: Configuration Assistant

    Chapter 2 HP NetServer Navigator For more information on installing and using HP NetServer Information Assistant, see Chapter 3. Configuration Assistant Configuration Assistant guides you through the steps necessary to configure the NetServer. Three methods of configuration are available: Express, Custom and Replicate.

  • Page 15: Hp Management Solutions

    Chapter 2 HP NetServer Navigator Execute Board Utilities: When HP NetServer Navigator finds installed boards for which there are additional configuration utilities on the CD- ROM, the configuration utilities are executed automatically to complete the configuration of the boards. Create Drivers Diskette: This step creates a customized diskette that contains HP drivers and configuration files to use when you are installing your NOS.

  • Page 16: Hp Netserver Utilities

    Chapter 2 HP NetServer Navigator Some of the features of NSA include: Disk capacity threshold alert and usage tracking SCSI controller and device failure notification Predictive disk problem warning backed by HP proactive warranty replacement PC LAN adapter board performance statistics, configuration, and problem information Error alerting and identification for the server’...

  • Page 17: Change User Preferences

    Chapter 2 HP NetServer Navigator Diskette Library: Allows you to conveniently generate any flexible disk available on the NetServer Navigator CD-ROM. For example, you can create the following flexible disk: BIOS Update, EISA Configuration Utility, NOS Drivers, NetServer Assistant, PowerWise Assistant, Diagnostic Assistant and Remote Assistant Upgrade.

  • Page 19: Hp Netserver Information Assistant, Hp Information Assistant Overview, Using Hp Netserver Information Assistant, Getting Help

    3 HP NetServer Information Assistant HP Information Assistant Overview HP NetServer Information Assistant provides a quick and efficient means to locate information about installing, managing and servicing your HP NetServer. Information Assistant has complete documentation on the HP NetServer and accessories as well as important information on your NOS.

  • Page 20: Finding Information

    Chapter 3 HP NetServer Information Assistant Finding Information Information Assistant provides you with many ways of navigating through its topics and locating information. For example, you can: Select a topic from the Map. Displays a window with an outline of every module, and topic in the Information Assistant for the selected product.

  • Page 21: Copying And Printing Information

    Chapter 3 HP NetServer Information Assistant You can also find information using drop-down menus and hot spots. For example: Lookup error number. This drop-down menu displays the Error Number dialog box in which you enter the error number for which you need information.

  • Page 22: Installing Hp Information Assistant Software, Installing From The Cd-rom, Installing From The Network

    Chapter 3 HP NetServer Information Assistant Installing HP Information Assistant Software HP Information Assistant runs on an HP Vectra or other PC running Windows 3.1 and above, Windows 95 or Windows NT. HP Information Assistant can be installed in one of two ways: From the CD-ROM From a Network Server on which the HP Information Assistant application files are installed...

  • Page 23

    Chapter 3 HP NetServer Information Assistant Installing the Application Files onto the Network To install the HP NetServer Information Assistant onto the network, perform the following steps: 1. Run Windows as you normally would, and display the Program Manager. 2. Insert the HP NetServer Information Assistant CD-ROM into the CD-ROM drive.

  • Page 25: Configuring Mass Storage, Mass Storage Indicator Lights

    4 Configuring Mass Storage The HP NetServer LD Pro chassis contains three horizontal mass storage shelves and a hot swap subsystem with three hot swap shelves. There are also openings in the chassis for connectors to provide connection to optional exterior mass storage subsystems.

  • Page 26: Shelf Locations

    Chapter 4 Configuring Mass Storage Shelf Locations This HP NetServer has three horizontal upper shelves and 3 hot swap shelves. The shelf number is not the SCSI address. The SCSI address is set by the switches on the devices in the upper horizontal shelves and the switches on the rear of the hot swap subsystem cage.

  • Page 27: Switch Settings On The Hot Swap Subsystem

    Chapter 4 Configuring Mass Storage Switch Settings on the Hot Swap Subsystem Figure 4-3 shows the switch settings on the rear of the hot swap subsystem cage. Switch settings are listed in the next section. The default settings can be found on the Technical Information Label, located on the side of the chassis, and in Information Assistant.

  • Page 28

    Chapter 4 Configuring Mass Storage Table 4-1 lists the possible settings for each switch. Always set switches 1, 2, and 6 to Off. Table 4-1. Hot-Swap Cage Switch Settings Switch Function Setting C Bus Setting Always set to Off C Bus Setting Always set to Off High/Low Addresses Sets drives to upper eight SCSI...

  • Page 29: Hot Swap Subsystem Scsi Address Settings

    Chapter 4 Configuring Mass Storage Hot Swap Subsystem SCSI Address Settings Switches 3 and 4 determine the SCSI ID for each shelf in the hot swap subsystem. Table 4-2 lists the possible IDs. NOTE For information on changing the CD-ROM drive SCSI address setting, see the Technical Information Label on the CD-ROM drive.

  • Page 30: Configuring Fast Scsi Or Ultra Scsi Mode, Configuring Ultra Scsi Mode In The Ecu

    Chapter 4 Configuring Mass Storage Configuring Fast SCSI or Ultra SCSI Mode This NetServer supports Fast SCSI and Ultra SCSI-specification mass storage devices. Both Fast SCSI and Ultra SCSI devices can be used on the same bus; the SCSI controller negotiates the appropriate bus speed for each specific SCSI device.

  • Page 31: Installing Ups Software, Before Installing Ups Software, Ups Installation For Microsoft Windows Nt

    5 Installing UPS Software Before Installing UPS Software Software for configuring, monitoring and managing the HP PowerWise UPS is located on the HP NetServer Navigator CD-ROM. Before installing your UPS software, you must first do the following steps: Install your UPS using the instructions in Step 2 of the HP NetServer LD Pro Road Map.

  • Page 32: To Install The Ups Software On The Hp Netserver

    Chapter 5 Installing UPS Software (Optional) HP NetServer Assistant is installed on your server and central management console, if you are using it to manage the server To Install the UPS Software on the HP NetServer NOTE You must have administrator access to the system in order to install this software.

  • Page 33: To Install The Ups Manager Application

    Chapter 5 Installing UPS Software 3. At the Command Line prompt, type the following: {drive}:\PWA\WINNT\DISK1\SETUP.EXE where {drive} is the letter of the CD-ROM drive. 4. Follow the instructions on the screen. You will be prompted to identify an installation path for the software. In the Installation Options window, select PowerWise Assistant (user interface only).

  • Page 34: Ups Installation For Novell Netware

    Chapter 5 Installing UPS Software UPS Installation for Novell NetWare NOTE Refer to the README file located in the \pwa\netware\disk1 directory on the HP NetServer Navigator CD-ROM for any updates to the installation procedure. If you do not have a client with Windows to manage the HP PowerWise UPS, refer to the README file located in the \pwa\netware\dos directory on the HP NetServer Navigator CD-ROM for the installation procedure.

  • Page 35

    Chapter 5 Installing UPS Software To Install the UPS Software on the HP NetServer NOTE You must have administrator capabilities to install this software. Install the HP PowerWise Assistant application on the HP NetServer to which the UPS is connected and on a local Windows client used to manage the server. With Novell NetWare, you can have more than one server connected to a UPS.

  • Page 36: To Install The User Interface On A Local Client Pc

    Chapter 5 Installing UPS Software To Install the User Interface on a Local Client PC Optionally, you can install the HP PowerWise user interface on an additional local client PC that you will be using to manage the HP PowerWise UPS. To install the UPS Software, perform the following steps: 1.

  • Page 37: Installing A Monochrome Monitor

    6 Installing a Monochrome Monitor The HP NetServer LD Pro supports both color and monochrome monitors. The NetServer is factory-configured for a color monitor. To configure the NetServer for a monochrome monitor, you must change the J16 jumper setting on the system board to the setting shown in Figure 6-1.

  • Page 39: Troubleshooting, Troubleshooting Tools

    7 Troubleshooting Troubleshooting Tools If you are having problems installing your HP NetServer, there are a number of different tools available for troubleshooting. These tools are available on your HP NetServer Navigator CD-ROM: HP NetServer Information Assistant: At the HP NetServer Navigator Main Menu, select “Access Information Assistant”...

  • Page 40: Common Installation Problems, Troubleshooting Sequence

    The following sections contain general procedures to help you locate installation problems. If you need assistance, it is recommended that you contact your reseller first. If you need to get assistance from Hewlett-Packard, refer to Chapter 8 for information on service and support.

  • Page 41: If The System Will Not Power On

    Chapter 7 Troubleshooting 3. Boot the system. If the system does not function, refer to the following procedures. If you get an error message, see the section “Error Messages.” If the System Will Not Power On Perform the following steps: 1.

  • Page 42: Error Messages

    Chapter 7 Troubleshooting 3. If the server still doesn’ t work, turn off the monitor, the server, and all external devices, and check the internal hardware, as follows: a. Unplug the power cord and all telephone cables. Remove the HP NetServer cover.

  • Page 43: Service And Support, System Design, Integration, And Support

    System Design, Integration, and Support The hardware, utility software, and any operating system or environment software supplied by Hewlett-Packard provide an enhanced, industry-standard base. A network operating system, utilities, and application software have been added to create your complete system.

  • Page 44: Information And Support When You Need It

    Chapter 8 Service and Support Information and Support When You Need It Hewlett-Packard offers a complete set of support and information sources— each discussed in this chapter: HP NetServer Navigator Release History and Status Report HP NetServer Information Assistant CompuServe discussion forum and library...

  • Page 45: Hp Netserver Navigator Release History And Status Report

    Chapter 8 Service and Support HP NetServer Navigator Release History and Status Report To ensure that you have the latest versions of the software, obtain the current HP NetServer Navigator Release History. The Release History is updated for each new release of the CD-ROM. The Release History briefly describes the following for each release: Major changes to the HP Navigator CD-ROM that were made for that release...

  • Page 46: Hp Netserver Navigator Subscription Service, Hp Netserver Navigator Cd-rom

    Chapter 8 Service and Support BBS: Call (1 408) 553-3500 download document 6005.txt from the NSNAVCD library CompuServe: GO HPPC download document 6005.txt from the NetServer library Fax: Call HP’ s fax system at (1 800) 333-1917. Outside the U.S. and Canada, call (1 208) 344-4809 from your fax machine. Request document number 6005.

  • Page 47: Compuserve Discussion Forum And Library

    CompuServe, the worldwide electronic information utility, provides support, technical data, and updated software drivers for the products of over 900 hardware and software manufacturers, including Hewlett-Packard. With a CompuServe account, you post your question publicly in a managed, focused forum dedicated to one manufacturer or topic. People who regularly visit that forum read your question and reply within a day or two.

  • Page 48: World Wide Web And Internet Ftp, Bulletin Board System, Automated Fax

    Chapter 8 Service and Support World Wide Web and Internet FTP HP has a home page on the Internet World Wide Web specifically for the HP NetServer http://www.hp.com/go/netserver You can also download NetServer files from HP via Internet FTP by entering the following: address: ftp://ftp.netserver.hp.com logon: anonymous...

  • Page 49: Hp Netserver Support News, Telephone Support

    Assistance with additional functions such as system design, operating system upgrades, or performance optimization— and assistance with other technical areas, such as cabling, non-HP hardware, or multiple operating system environments— is available from Hewlett-Packard, resellers, or consultants at...

  • Page 50: Obtaining Hp Repair And Telephone Support

    Chapter 8 Service and Support additional charge. For example, HP offers LAN Support Service, or Comprehensive Network Support Service with a 7-day, 24-hour option for network operating systems and multi-vendor hardware. Contact your local HP office for details. Obtaining HP Repair and Telephone Support The “Warranty and Software License”...

  • Page 51

    Chapter 8 Service and Support For hardware repair or telephone support in Europe, contact either: Participating Service Authorized HP Personal Computer Reseller HP Customer Support Center (Netherlands): France 04 50 43 9853 United Kingdom 0171 512 5202 Germany 069 92 03 22 40 Italy 02 2 641 0350 Sweden...

  • Page 52: Ordering Hp Cables, Drive Trays, And Technical Publications, Telephone Ordering Information

    Service and Support Ordering HP Cables, Drive Trays, and Technical Publications If you need more technical information, Hewlett-Packard publishes other references that you can order from HP, such as the HP NetServer Product Line Service Handbook. Service information and reference documents, such as the Dealer Configuration File Creation Guide (CFG), are also available in Information Assistant on the HP NetServer Navigator CD-ROM.

  • Page 53: Contacting Hp Regional Headquarters, Joining Compuserve

    Service and Support Contacting HP Regional Headquarters Should you need to contact Hewlett-Packard, check your local telephone directory for the HP Sales and Service Office near you. If you cannot locate an HP office, contact one of the Worldwide HP Marketing Headquarters listed here:...

  • Page 54

    Chapter 8 Service and Support Chile— ChilePac, Santiago France— CompuServe SARL, Rueil Hong Kong— CompuServe Hong Kong, Motorola AirCommunications Hungary— CompuServe Hungary, Middle Europe Network, Budapest Israel— CompuServe Israel, Trendline Info. Comm., Tel Aviv Japan— NIFTY Corporation, Tokyo Mexico— CompuServe Mexico, Infoacces S.A. de C.V., Mexico City South Africa—...

  • Page 55: Warranty And Software License, Hardware Product Limited Warranty, Software Product Limited Warranty, Hewlett-packard Utility Software

    Software Product Limited Warranty Hewlett-Packard Utility Software HP warrants for the period specified in the HP NetServer Limited Warranty Table section below that software and firmware products which are designated by...

  • Page 56: Third-party Software Products, Hardware Accessories Limited Warranty, Hewlett-packard Hardware Accessories

    On-site visits caused by third-party software products are subject to standard per- incident travel and labor charges. Hardware Accessories Limited Warranty Hewlett-Packard Hardware Accessories HP warrants this HP NetServer Hardware Accessory against defects in material and workmanship, under normal use, for the period specified in the HP NetServer Limited Warranty Table section below.

  • Page 57: Third-party Hardware Products, Pre-failure Warranty, Limitation Of Warranty

    Chapter 9 Warranty and Software License HP products external to the system processor unit, such as external storage subsystems, printers, or other peripherals, are covered by the applicable warranty for those products. Third-Party Hardware Products HP does not warrant third-party hardware products. Third-party hardware products may be warranted in accordance with the third-party warranty statement accompanying the product.

  • Page 58: Limitation Of Liability And Remedies, Customer Responsibilities

    Chapter 9 Warranty and Software License This warranty gives you specific legal rights. You may also have other rights that vary from state to state or province to province. Limitation of Liability and Remedies In no event will HP or its affiliates, subcontractors, or suppliers be liable for any of the following: 1.

  • Page 59

    Chapter 9 Warranty and Software License b. running HP-supplied configuration and diagnostics programs or following the problem determination, problem analysis, and service request procedures that HP or Reseller provides; c. securing all proprietary and confidential information; d. securing all programs and data; e.

  • Page 60: Obtaining Warranty Service, Customer Replacement Part, Return To Hp/reseller, On-site

    Chapter 9 Warranty and Software License Obtaining Warranty Service To obtain warranty service, Customer must contact HP or Reseller. The customer must be prepared to provide the product model number and serial number and may be required to provide dated proof of purchase. Depending on the product, warranty repair or replacement may be provided, at HP or Reseller's sole discretion, at Customer's location or "On-site", by the Return-to-HP/Reseller process, or by use of the Customer Replacement Part...

  • Page 61

    Chapter 9 Warranty and Software License Travel restrictions and response time for Reseller is defined by the participating reseller. On-site service is limited to products that remain in the country of original Customer purchase from HP or Reseller. Outside the country of original purchase, on-site warranty service is available only by prior arrangement either through purchase of the product at HP's International Price, with the destination specified at time of order, or through purchase of a service contract from the HP...

  • Page 62: Hp Netserver Limited Warranty Coverage

    Chapter 9 Warranty and Software License HP NetServer Limited Warranty Coverage Warranty Coverage Period Product Year 1 Year 2 Year 3 HP NetServer L Series On-site On-site On-site HP NetServer E Series On-site HP-developed Utility 90 days Software Media HP internal accessories (i.e.

  • Page 63: Technical Support, U.s. And Canada, Europe

    Chapter 9 Warranty and Software License Technical Support During the warranty period, telephone technical support is available to assist with setup, configuration, startup, and troubleshooting of your hardware product. Prior to calling HP or Reseller, please follow this checklist. This will allow HP or Reseller to assist you more quickly and efficiently.

  • Page 64: Asia/pacific, Other Countries

    Chapter 9 Warranty and Software License France: 04 50 43 9853 United Kingdom: 0171 512 5202 Germany: 069 92 03 22 40 Italy: 02 2 641 0350 Sweden: 08 619 2170 Belgium (Dutch): 02 626 8806 Belgium (French): 02 626 8807 Austria: 0660 6386 Denmark:...

  • Page 65: Self-help Tools, Supplemental Warranty Service And Support

    Chapter 9 Warranty and Software License Self-Help Tools Extensive technical information, product updates, and interactive forums are available 24 hours a day, 7 days a week. More detailed information regarding these tools may be obtained at HP's home page on the Internet World Wide Web. Bulletin Board Service: 1-408-553-3500 Internet World Wide Web:...

  • Page 66: Hp Netserver Warranty Frequently-asked Questions

    Chapter 9 Warranty and Software License HP NetServer Warranty Frequently-Asked Questions Q: What is the intention of the HP NetServer Warranty? A: The HP NetServer Warranty is intended to protect you from any defects in workmanship or materials of the hardware product for a period of time after your purchase.

  • Page 67

    Chapter 9 Warranty and Software License Q: Will adding third-party memory or disk drives void the warranty? A: Adding third-party memory or disk drives does not void the warranty. However, there are some implications when you need technical support. For example, when the memory used may relate to the problem you are experiencing, you will be asked to remove the third-party memory to confirm the problem still exists before a service provider is dispatched.

  • Page 68

    Chapter 9 Warranty and Software License Q: What is the response time for on-site warranty service? A: The standard response time for on-site warranty service is end of next business day. All response commitments are based on commercially reasonable efforts by HP and HP Authorized Service Providers. Q: Can I keep the defective part that is being replaced? A: No.

  • Page 69

    Chapter 9 Warranty and Software License Q: What are my options if I want network or server application software support? A: Network or server application software support services are available to complement the HP NetServer Warranty. Examples of these services include: per-incident bundled (5-pack or 10-pack) network support, annual network support, and...

  • Page 70

    Chapter 9 Warranty and Software License a. ensure that all HP NetServer covers, panels, and board retainers are in place to provide proper airflow whether the system is free-standing, rack-mounted, or being shipped; b. establish and practice back-up procedures for your data and programs to minimize any disruptions to your business in case of a hardware failure;...

  • Page 71

    Chapter 9 Warranty and Software License applicable error messages from system or diagnostics applicable hardware driver revision levels add-on boards or hardware third-party hardware or software operating system type and revision level Q: How can I track changes that could affect the operation of my HP NetServer? A: Many customers have found it extremely useful to keep a system log.

  • Page 72

    Chapter 9 Warranty and Software License are available from HP or an Authorized HP Reseller at an additional charge.

  • Page 73: A Control Panel Description

    A Control Panel Description Table A-1 describes each item on the control panel shown in Figure A-1: Hard Disk Activity Light Yellow = Embedded SCSI or IDE bus active Power-On Light Green = Power is on Power Button Reset Button Keyboard Lock Light Yellow = Keyboard is locked...

  • Page 74

    Appendix A Control Panel Description Table A-1. Control Panel Description Control Panel Item Description Power Button Turns the NetServer on and off. Note that when the NetServer is turned off, the power to the internal circuitry and mass storage devices is disabled;...

  • Page 75: B Specifications, Environment

    B Specifications The specifications listed below can vary if you install a mass storage device in your server that has more stringent environmental limits. Make sure that the operating environment for your server is suitable for all the mass storage devices that you are using.

  • Page 76: Weight And Dimensions, Power Supply Specifications

    Appendix B Specifications Weight and Dimensions System Processing Unit (SPU) Height 491 mm (19.33 in) Width 349 mm (13.74 in) Depth 460 mm (18.11 in) Weight 31 – 41 kg (67 – 90 lb) depending on other model configurations. Weight excludes monitor and keyboard.

  • Page 77: C Regulatory Information, Notice For Usa, Fcc Radio Frequency Emissions Statements

    Consult the dealer or an experienced radio/television technician for help. Hewlett-Packard’ s system certification tests were conducted with HP-supported peripheral devices and HP shielded cables, such as those you receive with your computer. Changes or modifications not expressly approved by Hewlett-Packard could void the user’...

  • Page 78: Cd-rom

    Appendix C Regulatory Information when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user is required to correct the interference at their own expense.

  • Page 79: Notice For Canada: Doc Requirements, Notice For Eu, Radio Frequency Emissions Warning For Accessories

    Appendix C Regulatory Information Notice for Canada: DOC Requirements This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Notice for EU: Radio Frequency Emissions Warning for Accessories Installation and use of a Class A accessory (such as a network interface board)

  • Page 80: Declaration Of Conformity

    The product herewith complies with the requirements of the Low Voltage Directive 73/23/EEC and the EMC Directive 89/336/EEC. 1) The Product was tested in a typical configuration with Hewlett-Packard peripherals. 2) Models configured with a network interface board comply with CISPR 22 / EN 55022 Class B limits.

  • Page 81: Notice For Finland: Laser Safety Statement, Notice For Germany, Noise Declaration And Ergonomics

    Appendix C Regulatory Information Notice for Finland: Laser Safety Statement LASERTURVALLISUUS LUOKAN 1 LASERLAITE KLASS 1 LASER APPARAT HP NetServer Pro - verkkopalvelimeen voidaan asentaa lisävarusteena laitteensisainen CD-ROM-lukulaite, joka on laserlaite. Kyseinen CD-ROM-lukulaite on käyttäjän kannalta turvallinen luokan 1 laserlaite. Normaalissa käytössä lukulaitteen suojakotelo estää laseräteen pääsyn laiteen ulkopuolelle.

  • Page 82: Notice For Japan, Vcci Statement

    Appendix C Regulatory Information VORSICHT Die Verwendung von anderen Steuerungen oder Einstellungen oder das Durchführen von anderen Vorgängen als in der Bedienungsanleitung beschrieben kann gefährliche Strahlenexpositionen zur Folge haben. This CD-ROM Drive Unit is classified as a CLASS 1 CLASS 1 LASER PRODUCT.

  • Page 83: Power Line Harmonics, Notice For Korea: Rfi Statement, Mexico: Hardware Warranty Statement

    Mexico: Hardware Warranty Statement This warranty statement applies only to sales in Mexico. Póliza de Garantía Hewlett-Packard de México, S. A. de C. V. con domicilios en: Guadalajara, Jalisco Monterrey, Nvo. León Montemorelos No. 299 Calz. Del Valle O. No. 409 Fracc.

  • Page 84

    Los gastos de transportación que se deriven de su cumplimiento serán cubiertos por Hewlett-Packard de México, S. A. de C. V. 3. Tiempo de Reparación: El tiempo de reparación en ningún caso será mayor a treinta días contados a partir de la recepción del producto en cualquiera de los sitios en donde...

  • Page 85: Notice For U.k.: General Approval

    Appendix C Regulatory Information C. Cuando el producto ha sido alterado o reparado por personas no autorizadas por Hewlett-Packard de México, S.A. de C. V. Producto Marca Modelo No. de Serie Nombre del Distribuidor Dirección : ( Calle, Número, Colonia o Poblado, Delegación o Municipio ) C.P.

  • Page 87: Index

    Keyboard Lock button, 68 warranty information for, 49 Keyboard Lock light, 68 help, 37 CompuServe, 41, 47 electronic newsletter, 43 Management Software, 40 FAX systems for, 42 Mass Storage for system and software support, 37 from Hewlett-Packard, 47...

  • Page 88

    Index hot swap subsystem SCSI address switch settings, 23 software hot swap subsystem switch settings, support for, 37 21, 22 support indicator lights, 19 Release History, 39 shelf numbering, 20 Status Report, 39 monochrome monitor installation, 31 system configuration, 8 system support, 37 Navigator Release History, 39...
