Step 1—Preparing for component installation
NOTE: Workstation models vary. All illustrations are examples only.
Accessing the internal components of the workstation
1. If you need help preparing the workstation for this installation, consult the removal and replacement
procedures in the service guide for your workstation at
workstation_manuals.
NOTE:
Guide on the Documentation and Diagnostics CD that shipped with your workstation.
2. Power down the workstation, and then disconnect the power cord.
3. Power down all external devices, and then disconnect them from the workstation.
4. Remove the side access panel.

Removing components

1. If installing in an HP
bays.
2. If present, remove the card support to enable access to the system board connectors.
3. Remove the front bezel if applicable.
NOTE:
4. Remove the filler from the lowest available optical drive bay.
ENWW
For the HP Workstation series, these procedures are also available in the User
800 Workstation, remove the airflow guide to enable access to the optical
The front bezel does not need to be removed on HP
http://www.hp.com/support/
600 and HP
Step 1—Preparing for component installation
800 Workstations.
