Step 1—Preparing for component installation

NOTE:

Computer models vary. All illustrations are examples only.

Download and install updates

Check for available system BIOS updates specified for your HP computer model and operating

system at http://www.hp.com/support.

Install the system BIOS updates, if available.

Accessing the internal components of the computer

If you need help preparing the computer for this installation, consult the removal and

replacement procedures in the service guide for your computer at

manuals.

Power down the computer, and then disconnect the power cord.

Power down all external devices, and then disconnect them from the computer.

Remove the side access panel.

Removing components

If present, remove the card support to enable access to the expansion slots and system board

connectors.

Select the smallest available expansion slot for a PCIe expansion card and remove the slot

cover. The Broadcom NIC can be installed in a PCIe x1, x4, x8, or a x16 expansion slot.

NOTE:

access panel.

Figure 1

ENWW

To identify an available PCIe expansion slot, see the service label on the workstation

Removing the expansion slot cover

http://www.hp.com/support/

Step 1—Preparing for component installation
