1.5.2

USB

The board provides up to seven USB 2.0 ports, supports UHCI and EHCI, and uses
UHCI- and EHCI-compatible drivers (four ports routed to the back panel and three
ports routed to two front panel USB 2.0 headers). One of the front panel USB headers
(brown-colored) supports an Intel Z-U130 USB Solid-State Drive or compatible device.
NOTE
Computer systems that have an unshielded cable attached to a USB port may not
meet FCC Class B requirements, even if no device is attached to the cable. Use
shielded cable that meets the requirements for full-speed devices.
For information about
The location of the USB connectors on the back panel
The location of the front panel USB headers
1.5.3

SATA Support

The board provides two SATA interface connectors that support one device per
connector.
The board's SATA controller offers independent SATA ports with a theoretical
maximum transfer rate of 3.0 Gb/s on each port. One device can be installed on each
port for a maximum of two SATA devices. A point-to-point interface is used for host to
device connections, unlike PATA which supports a master/slave configuration and two
devices on each channel.
For compatibility, the underlying SATA functionality is transparent to the operating
system. The SATA controller supports IDE and AHCI configuration and can operate in
both legacy and native modes. In legacy mode, standard ATA I/O and IRQ resources
are assigned (IRQ 14 and 15). In native mode, standard Conventional PCI bus
resource steering is used. Native mode is the preferred mode for configurations using
the Windows Vista* operating system.
For information about
Obtaining AHCI driver
The location of the SATA connectors
Product Description
Refer to
Figure 9, page 39
Figure 11, page 41
Refer to
Section 1.2, page 16
Figure 11, page 41
