Intel Desktop Board D2700DC Technical Product Specification
Table 16. Front Panel USB Header
Pin Signal Name
1 +5 VDC
3 D-
5 D+
7 Ground
9 KEY (no pin)
Table 17. Front Panel USB Header with Intel Z-U130 USB Solid-State Drive or

Compatible Device Support

Pin Signal Name
1 +5 VDC
3 D-
5 D+
7 Ground
9 KEY (no pin)
44
Pin Signal Name
2 +5 VDC
4 D-
6 D+
8 Ground
10 No Connect
Pin Signal Name
2 NC
4 NC
6 NC
8 NC
10 LED#
