Intel Desktop Board D2700DC Technical Product Specification
1.4

System Memory

The board has two 204-pin DDR3 SO-DIMM sockets and supports the following
memory features:
• DDR3 SDRAM SO-DIMMs with gold-plated contacts
• Unbuffered, single-sided or double-sided DIMMs
• 4 GB maximum total system memory
• Minimum total system memory: 256 MB
• Non-ECC DIMMs
• Serial Presence Detect
• DDR3 1066 MHz, DDR3 1333 MHz, DDR3 1600 MHz SO-DIMMs
(DDR3 1333 MHz and DDR3 1600 MHz memory will run at 1066 MHz)
NOTE
Due to passively-cooled thermal constraints, system memory must have an operating
temperature rating of 85
The board is designed to be passively cooled in a properly ventilated chassis. Chassis
venting locations are recommended above the system memory area for maximum
heat dissipation effectiveness.
NOTE
To be fully compliant with all applicable DDR3 SDRAM memory specifications, the
board should be populated with SO-DIMMs that support the Serial Presence Detect
(SPD) data structure. This allows the BIOS to read the SPD data and program the
chipset to accurately configure memory settings for optimum performance. If non-
SPD memory is installed, performance and reliability may be impacted or the SO-
DIMMs may not function under the determined frequency.
18
o
C.
