Intel Desktop Board D2700DC Technical Product Specification
Table 10 lists the component-side connectors and headers identified in Figure 11.
Table 10. Component-side Connectors and Headers Shown in Figure 11
Item/callout
from Figure 11
A
B
C
D
E
F
G
H
I
J
K
L
42
Description
Processor core power connector (2 x 12)
SATA connector
SATA connector
System fan header
Front panel header
Front panel USB 2.0 header
Front panel wireless activity LED header
Piezo/monotonic speaker header
PCI Express Full-/Half-Mini Card slot
Conventional PCI bus add-in card connector
Front panel audio header
Front panel USB header supports Intel Z-U130 USB Solid-State Drive or compatible
device (brown-colored)
