Signal Tables for the Connectors and Headers
Table 11. System Fan Header
Pin
Signal Name
1
Ground
2
+12 V (PWM controlled pulses)
3
Tach
Table 12. SATA Connectors
Pin
Signal Name
1
Ground
2
TXP
3
TXN
4
Ground
5
RXN
6
RXP
7
Ground
Table 13. Front Panel Wireless Activity LED Header
Pin
Signal Name
1
Ground
2
MINICARD_WLAN#
Table 14. Front Panel Audio Header for Intel HD Audio
Pin
Signal Name
1
[Port 1] Left channel
3
[Port 1] Right channel
5
[Port 2] Right channel
7
SENSE_SEND (Jack detection)
9
[Port 2] Left channel
Table 15. Front Panel Audio Header for AC '97 Audio
Pin
Signal Name
1
MIC
3
MIC_BIAS
5
FP_OUT_R
7
AUD_5V
9
FP_OUT_L
Pin
Signal Name
2
Ground
4
PRESENCE# (Dongle present)
6
[Port 1] SENSE_RETURN
8
Key (no pin)
10
[Port 2] SENSE_RETURN
Pin
Signal Name
2
AUD_GND
4
AUD_GND
6
FP_RETURN_R
8
KEY (no pin)
10
FP_RETURN_L
Technical Reference
43
