SSIM-A2-01/SSIM-A8-01
ATM 155
SmartStack Interface Modules
Installation
and
User Guide

Advertisement

Table of Contents
loading

Related Manuals for Cabletron Systems SSIM-A2-01

Summary of Contents for Cabletron Systems SSIM-A2-01

  • Page 1 SSIM-A2-01/SSIM-A8-01 ATM 155 SmartStack Interface Modules Installation User Guide...

  • Page 2: Fcc Notice

    NOTICE Cabletron Systems reserves the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made. The hardware, firmware, or software described in this manual is subject to change without notice. IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS MANUAL OR THE INFORMATION...

  • Page 3: Industry Canada Notice

    INDUSTRY CANADA NOTICE This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique édicté...

  • Page 4: United States Government Restricted Rights

    CABLETRON SOFTWARE PROGRAM LICENSE LICENSE. You have the right to use only the one (1) copy of the Program provided in this package subject to the terms and conditions of this License Agreement. You may not copy, reproduce or transmit any part of the Program except as permitted by the Copyright Act of the United States or as authorized in writing by Cabletron.

  • Page 5: Declaration Of Conformity

    DECLARATION OF CONFORMITY Application of Council Directive(s): 89/336/EEC 73/23/EEC Manufacturer’s Name: Cabletron Systems, Inc. Manufacturer’s Address: 35 Industrial Way PO Box 5005 Rochester, NH 03867 European Representative Name: Mr. J. Solari European Representative Address: Cabletron Systems Limited Nexus House, Newbury Business Park London Road, Newbury Berkshire RG13 2PZ, England Conformance to Directive(s)/Product Standards:...

  • Page 6: Table Of Contents

    Table of Contents 1. Introduction 2. Installation Package Contents ......3 Rules to Remember ......4 Frame Length Limit.
  • Page 7 Frame-Forwarding Statistics....48 LANE Status ......52 Server VCC Table .
  • Page 8 List of Figures Figure 1. SSIM-A2-01 Uplink (right) and SSIM-A8-01 Uplink (left) ..1 Figure 2. Unsupported Configuration ....5 Figure 3.
  • Page 9 viii Summary of Contents Following is a short description of the content of the chapters and appendixes in this publication: Chapter 1, “Introduction”, is a general introduction to the SSIM-A2-01 ATM 155 Uplink UTP5 module and the SSIM-A8-01 ATM 155 Uplink MMF module. Chapter 2, “Installation”, lists the SSIM-Ax-01 module package contents, explains module installation and cabling, describes the front panel LEDs, and explains configuration and testing of the module.

  • Page 10: Introduction

    1. Introduction The SmartStack SSIM-A2-01 and SmartStack SSIM-A8-01 ATM 155 Uplink Modules from Cabletron Systems provide high-speed connections to the ATM backbone for the STS16-20RM Token-Ring Switch. Designed for high performance and low latency, these modules provide connectivity between existing legacy Token Ring networks and ATM networks.
  • Page 11 SmartStack SSIM-A2-01/SSIM-A8-01 Introduction...

  • Page 12: Installation

    2. Installation This chapter contains instructions for installing, connecting and testing the SSIM- Ax-01 module. This chapter contains the following information: • Package Contents • Rules to Remember • Installation Procedure • Hardware Installation • Software Installation • Cabling • LEDs •...

  • Page 13: Rules To Remember

    Rules to Remember This section will help you understand the configuration restrictions for the SSIM- Ax-01 ATM 155 Uplink Module. In brief, you must remember the following rules when planning to install the uplink: • Only one VAP per uplink per VLAN •...

  • Page 14: One Vap Per Uplink Per Vlan

    One VAP per Uplink per VLAN The SSIM-Ax-01 module does not allow configurations in which the following frame operations take place within a single uplink module: • Bridging from ATM back to ATM. • Broadcasting a frame from Token Ring to more than one ATM ELAN. These operations would occur if the uplink module provided more than one VAP per VLAN.

  • Page 15: Spanning Tree

    If you connect to the same ATM ELAN more than once from the same VLAN, you are using parallel bridges. When doing so, you must always enable the Spanning Tree function for all the CRFs that have parallel paths. With more than one uplink, you can connect more VLANs to ATM while at that same time creating backup connections.

  • Page 16: Installation Procedure

    Installation Procedure The SSIM-Ax-01 module is packaged with software for both the module and the base STS16-20RM Token Ring Switch. The switch is also packaged with software for both the module and the switch. To ensure compatibility between the module and the switch, you must install the later of the two software revisions.

  • Page 17: Hardware Installation

    Hardware Installation Use the following steps to install the SSIM-Ax-01 module in a STS16-20RM Token Ring Switch: 1. Power off the base switch by unplugging the power cord from the power outlet. If the switch uses the optional SmartStack STS-PSU Redundant Power Supply Unit, unplug the connector from the base switch as well.

  • Page 18: Software Installation

    Software Installation Before you can use your SSIM-Ax-01 module, you must install the uplink module software. The module software can be downloaded via TFTP or via a serial line. Search the disks supplied with the module for a file named ATMyzv.bin. The letters yzv in the file name represent the version number of the software.

  • Page 19: Serial Download

    The console will display the download activity while the software is transferred over the network. When the software has been transferred, you will see the following messages: Network download complete. Now transferring to ATM Module(s), please wait... Download of ATM firmware complete - ATM module(s) being reinitialized...

  • Page 20: Cabling

    Cabling The cabling used depends on which version of the module you are installing. SSIM-A2-01 ATM 155 Uplink UTP5 The SSM-A2-01 module uses standard copper UTP5 cabling. The maximum cable length is 100 m (328 feet). 1. Insert the modular jack from either end of an RJ45 UTP-5 cable into the connector on the SSM-A2-01 front panel.

  • Page 21: Leds

    LEDs There are four LEDs on the front panel of the SSIM-Ax-01 module. The LEDs show the module status and activity. Table 2 explains the status LEDs on the left of the module front panel, and Table 3 explains the ATM interface LEDs on the right of the module front panel.

  • Page 22: Testing The Module

    State DIAG RXSYNC On (green) SIGLOSS Table 4. Normal LED State Testing the Module 1. Power on the base switch to start diagnostics. Diagnostics are in progress when the STS16-20RM DIAG LED is on. After about a minute, the SSIM-Ax-01 DIAG LED will turn on, indicating that the expansion module diagnostics are in progress.

  • Page 23: Configuration

    Configuration The SSIM-Ax-01 module can be configured using the RS-232-based console configuration, Telnet, or the SNMP-based management application. (The SNMP- based management application is described in the online help). Default Configuration When the module is inserted for the first time, the module will be configured with the default configuration, as described below: •...

  • Page 24: Console Configuration

    3. Console Configuration This chapter explains how to view and edit the configuration of the SSIM-Ax-01 ATM 155 Uplink Module using a VT100 console attached directly to the STS16- 20RM Token Ring Switch. The module configuration can also be modified from a remote VT100 console via a telnet session.

  • Page 25: Introduction

    Introduction In the console configuration, port numbers are used to refer to ports, with the ordinary Token Ring ports being numbered 1 to 20. Using the console, the ATM port will appear as port 21 when located in the left hand slot, and as port 25 when located in the right hand slot.

  • Page 26: Navigating Within The Menus

    • To refresh the console panel at any time, press CTRL-L • If you are administering switches in a stack, many of the console screens will prompt for a box number. Enter the number of the box you want to administer to continue.

  • Page 27: Atm Configuration - Port Menu

    ATM Configuration - Port Menu To change the configuration of the SSIM-Ax-01 ATM 155 Uplink Module, select Port Configuration from the Configuration menu and type the port number when prompted. The following menu is displayed. The following items are available: Enabled Sets the administrative state of the port.

  • Page 28: Atm Network Configuration

    ATM Network Configuration To view and edit the ATM network configuration, select ATM Network Setup from the ATM Configuration - menu. The following information is displayed on this screen: ATM Network Parameters Master Timing Sets the source of transmit timing. When connected to an ATM switch, the ATM switch will always be the master.
  • Page 29 Maximum Active ATM Virtual Channel Bits VPI:VCI Selects the active Virtual Path Identifier (VPI) and Virtual Connection Identifier (VCI) bit combination. Possible values: 0:12 (default), 1:11, and 2:10. ILMI Parameters The VPI value for the ILMI PVC. Possible values: 0 to 3. Default: 0.
  • Page 30 Max Line Rate (cells/sec) Sets the maximum peak rate of the physical link between the module and the ATM switch. The value set affects all VCCs regardless of their individual traffic profile settings. Possible values: from 353 through 353,208. Default: 353,208 (approximately 150 Megabits per second). Total # Simultaneous SVC calls in progress Sets the maximum number of ATM calls in progress.

  • Page 31: Atm Network Advanced Parameters

    ATM Network Advanced Parameters To view and edit advanced network parameters for the ATM network, select Advanced Parameters on the ATM Network Setup screen. The following items are available in the SSCOP section of the screen: SSCOP Maximum Receive Window Size Sets the maximum SSCOP protocol receive window size in bytes.
  • Page 32 Maximum Number Elements in STAT PDU Sets the maximum number of list elements placed in a STAT PDU. Possible values: 3 to 1023. Default: 67. Maximum SDU Size (bytes) Sets the maximum size of the service data unit (SDU) in bytes. Possible values: 512 to 16,384.
  • Page 33 Connection Control Timer (tenths of sec) Sets the value of the Connection Control Timer variable. As a guideline, set the value greater than Timer_POLL and round-trip delay. Possible values: 1 to 255. Default: 1. Signal Timing Settings (in seconds) This section of the screen contains advanced signalling parameters as described below.
  • Page 34 T316 The maximum time to wait for response to RESTART. Possible values: 1 to 255. Default: 120. T317 The maximum time to act on RESTART. The value set should be less than T316. Possible values: 1 to 255. Default: 60. T322 The maximum time to wait for response to STATUS ENQUIRY.

  • Page 35: Atm Lec Main Configuration Screen

    ATM LEC Main Configuration Screen To view and edit the ATM LEC setup, select ATM LEC Setup from the ATM Configuration menu. If there are multiple VAPs, you will be prompted for the VAP you want to configure. The VAP name is shown in the title bar. Enabled Sets the administrative state of the Virtual ATM Port (VAP) connecting the CRF to the ELAN.
  • Page 36 Value Meaning The VAP is up but not forwarding Forwarding The VAP is up and forwarding Table 6. Current Status Information of the VAP ATM Forum: C3 Sets the Maximum Transmission Unit of the ELAN. Possible values: 1500 and 4472, 8144, 17800 and Use BRF (default).). These values correspond to the standard values used on ordinary Token Ring ports.
  • Page 37 Max Rx Rate Threshold (cells/sec) Sets the maximum difference between the requested receive rate of an incoming LANE call and the line rate, above which the call is rejected with the cause “User cell rate not available”. Note that the default value of this parameter effectively disables checking of the requested receive rate.

  • Page 38: Traffic Profiles

    Traffic Profiles Traffic profiles describe the characteristics of the transmitted data. All VCCs (SVC or PVC) created by the uplink software and the LES are assigned a traffic profile, and for the typical ATM LAN setup, the default profile is sufficient. However, under certain circumstances it may be necessary to change the traffic profiles and their usage.
  • Page 39 Traffic profiles are used in three different situations, listed below, which again require three different methods for assigning the correct traffic profiles to the correct VCC. 1. PVCs are assigned a designated traffic profile when they are created during startup. The designated profile is simply specified in the configuration. 2.

  • Page 40: Traffic Profile Mapping Configuration

    Traffic Profile Mapping Configuration To view and edit traffic profile mappings, select Traffic Profile Mapping from the ATM LEC Setup screen. Target ATM Address Specifies the target ATM address. This address is compared with the destination address (after it has been ANDed with the address mask) for the VCC to be opened. ATM Address Mask Specifies the ATM address mask.

  • Page 41: Atm Lane Parameters Configuration

    ATM LANE Parameters Configuration To view and edit ATM LANE parameters, select LANE Parameters on the ATM LEC Setup screen. LANE ATM Address ATM Forum: C1 The ATM address for the ELAN can be assigned manually or automatically. If you select Automatic, the address is constructed using a 13 byte address prefix provided by the ATM switch, the 6 byte burned-in MAC address of the STS16-20RM, and a 1 byte selector.

  • Page 42: Figure 7. Contacting Lan Emulation Services

    LAN Emulation Configuration Server (LECS) The module port uses the method shown in Figure 7 to get in contact with LAN emulation services. The figure shows how specification of the LES address, LECS PVC (VPI/VCI) or LECS address can be used to identify particular LAN emulation services.
  • Page 43 Sets the virtual path identifier of the LECS PVC. Possible values: 0 (default), 1, 2 and 3. Sets the virtual channel identifier of the LECS PVC. Possible values: 0 (default) to 4095. Address Specifies the ATM address of the LECS. LAN Emulation Client ELAN Name ATM Forum: C5...
  • Page 44 Max Unknown Frame Time (sec) ATM Forum: C11 Sets the time period in seconds in which the LANE client can send a maximum of MaxUnknownFrameCount frames (see above) to the BUS, before the LANE client begins to resolve the LANE destination using LE_ARP. Possible values: 1 to 60.
  • Page 45 VCC Timeout (sec) ATM Forum: C12 Sets the VCC timeout period in seconds. A LANE client must release any data direct VCC (DD-VCC) that has not been used to transmit or receive any data frames for the length of the VCC timeout period. This parameter is only valid for SVC DD- VCCs.

  • Page 46: Atm Lec Pvc Configuration

    ATM LEC PVC Configuration To view and edit PVC parameters, select PVC Parameters from the ATM LEC Setup screen. The system-supplied ID for the PVC. The ID is used when selecting a PVC for delete. Specifies the virtual path identifier of the PVC. Specifies the virtual channel identifier of the PVC.

  • Page 47: Atm Traffic Profile Configuration

    ATM Traffic Profile Configuration For a discussion of the traffic profile concept, refer to the section “Traffic Profiles” on page 29. To view and edit the ATM traffic profiles, select Traffic Profiles Table from the ATM Configuration screen. The following information is displayed. The traffic profile number, used to identify a row of traffic parameters for use in other panels.
  • Page 48 Peak Rate Specifies the maximum rate in cells/sec that data will be transmitted. Cell rates are approximated by the hardware, so the actual peak cell rates used are as close to the specified rates as permitted by the hardware. Consequently, statistics programs may show cell rates as being slightly different from the specified rates.
  • Page 49 SmartStack SSIM-A2-01/SSIM-A8-01 Console Configuration...

  • Page 50: Statistics

    4. Statistics A wide range of statistics is available for the SSIM-Ax-01 ATM 155 Uplink Module. The following topics are discussed in this chapter: • Statistics Menu • Port Status • Port Statistics • General ATM Statistics • LEC Statistics •...

  • Page 51: Statistics Menu

    Statistics Menu To access the statistics menu, select Statistics from the Main menu. The following menu is displayed: The menu items shown in the illustration above are described in the manual you received with your STS16-20RM Token-Ring Switch. For more information about the menu items, refer to that manual.

  • Page 52: Port Status

    Port Status To access the port status screen, select Port Status from the Statistics menu. The SSIM-Ax-01 ATM 155 Uplink Module will be listed as port 21 or port 25. A sample screen is shown below. Port Shows the port number of the port, used to identify the port on the system. TrCRF Shows the name of the CRF that the port or VAP belongs to.

  • Page 53: Port Statistics

    Oper Mode The operation mode is always displayed as ATM ELAN for ATM VAPs. Fwd Mode The forwarding mode is always displayed as Store-Fwd, since the module always operate in the store-and-forward switching mode. Port Statistics The ATM Statistics menu provides access to ATM-specific statistics. To show the menu, select Port Statistics from the Statistics menu and type the port number.

  • Page 54: General Atm Statistics

    General ATM Statistics To view general ATM statistics, select General ATM Statistics on the ATM Statistics menu. General Statistics Total Bytes The total number of bytes sent or received on the ATM network (the AAL5 payload). Unicast Frames The number of AAL5 frames (frames for specific network devices) sent or received on the ATM network.
  • Page 55 Invalid Tag The number of frames in the transmit direction (to ATM) that were dropped due to an invalid tag. Dropped Frames The number of frames dropped due to receive congestion at the beginning of the frame. CRC Errors The number of frames received from the ATM network with CRC errors. Overflow Errors The number of frames dropped due to receive congestion after the module has started receiving the frame.

  • Page 56: Lec Statistics

    LEC Statistics The LEC Statistics menu provides access to statistics that are relevant for emulated LANs. SmartStack SSIM-A2-01/SSIM-A8-01 Statistics...

  • Page 57: Frame-Forwarding Statistics

    Frame-Forwarding Statistics The Frame Forwarding Statistics screen provides statistics for traffic received on the ATM network for a particular ELAN. All statistics shown are for this VAP. Bytes Received The total number of bytes received on this VAP from the ATM network. Bytes Transmitted The total number of bytes transmitted on this VAP to the ATM network.
  • Page 58 ARP Replies Rx The number of LE_ARP_RESPONSEs received by the LEC from the ATM network. The counter includes both solicited and unsolicited replies. Replies may arrive on the Control Direct VCC or on the Control Distribute VCC, depending on how the LES is implemented. This counter covers both VCCs. ARP Replies Tx The number of LE_ARP_RESPONSEs transmitted by the LEC on this VAP.
  • Page 59 Invalid RIF RC Field The number of times a frame containing an illegal routing control field has been detected by the VAP. RIF Length Exceeded The number of frames detected by the VAP where the frame contains a RIF field that is too long.
  • Page 60 STE Frames The number of spanning-tree explorer frames transmitted or received on the ATM network on this VAP. ARE Frames The number of all-routes explorer frames transmitted or received on the ATM network on this VAP. Type Rx Unicast The number of frames received on this VAP with a non-broadcast destination address.

  • Page 61: Lane Status

    LANE Status The LANE Status screen displays the status for a VAP. ELAN State The forwarding state of the VAP. ELAN Name The name of the emulated LAN that this LEC last joined or wishes to join. ELAN Type The data frame format that the LAN Emulation Client is using. For the SSIM-Ax-01 mounted in the STS16-20RM Token-Ring Switch, the ELAN type will always be 802.5 (Token Ring).
  • Page 62 LEC Status LEC ID The LAN emulation client ID. During the join phase, the LAN emulation server assigns each client with a client identifier (LECID). The LECID is placed in control requests by the LEC and can be used for echo suppression on multicast data frames. Valid LECIDs are from X'0001' through X'FEFF'.
  • Page 63 Response Code The status code from the last failed Configure response or Join response. Failed responses are those for which the LE_CONFIGURE_RESPONSE or LE_JOIN_RESPONSE frame contains a failure code, or fails to arrive within a timeout period. If none of the client’s requests have failed, this field has the value None.

  • Page 64: Server Vcc Table

    Server VCC Table The Server VCC Table screen displays LANE server VCC information for a VAP. Configure Direct The VPI and VCI values for the VCC to the LECS. If an SVC is used, the SVC is closed after the configuration phase. If the VCCs are not in use, the values will be 0/0.

  • Page 65: Le-Arp Table

    LE-ARP Table The LE-ARP Table screen displays LANE address resolution information for a VAP. MAC Address The destination MAC address. ATM Address The destination ATM address. Shows if the MAC address is represented by a proxy (a LANE bridge). Rem is an abbreviation for remote.

  • Page 66: Route Descriptor Table

    Route Descriptor Table The Route Descriptor Table displays LANE address resolution information for a VAP. Bridge The destination bridge number. Segment The destination ring number. ATM Address The destination ATM address. Entry Type Shows how the entry was created. The entry can be created by a LANE control message (LE_ARP), learned by data, or statically configured.

  • Page 67: Lec Vcc Statistics

    LEC VCC Statistics The LEC VCC Statistics screen displays VCC statistics for a VAP. VPI/VCI The VPI/VCI value of the VCC. Usage Shows the VCC usage. Possible values are Cdirec (Control Direct), Cdist (Control Distribute), M-Send (Multicast Send), M-Forw (Multicast Forward) and Ddirec (Data Direct).

  • Page 68: Vcc Statistics

    VCC Statistics To view virtual channel connection statistics, select VCC Statistics on the ATM Statistics menu. The virtual path identifier of the VCC. The virtual channel identifier of the VCC. Usage Identifies the ATM components using this VCC. ATM Address The ATM address of the remote end of the VCC.
  • Page 69 Peak Rate The peak rate of the VCC. See “Peak Rate” on page 39. The quality of service of the VCC. See “QOS” on page 38. Frame Discard Indicates if the switch is allowed to discard all complete AAL5 frames if any single cells are lost from an AAL5 frame.

  • Page 70: Getting In Touch With Technical Support

    5. Getting in Touch with Technical Support For additional support related to this device or document, contact Cabletron Systems using one of the following methods: World Wide Web http://www.cabletron.com/ Phone (603) 332-9400 Internet mail support@cabletron.com ftp://ftp.cabletron.com/ Login anonymous Password your email address To send comments or suggestions concerning this document, contact the Cabletron Systems Technical Writing Department via the following email address: TechWriting@cabletron.com...
  • Page 71 SmartStack SSIM-A2-01/SSIM-A8-01 Getting in Touch with Technical Support...

  • Page 72: Appendix A. Abbreviations

    Appendix A. Abbreviations ATM Adaption Layer All-Route Explorer Address Resolution Protocol Asynchronous Transfer Mode Bridge Relay Function Broadcast and Unknown Server CD-VCC Control Distribute VCC CDIR-VCC Control Direct VCC Cyclic Redundancy Check Concentrator Relay Function DD-VCC Data Direct VCC Engineering Change Order Emulated LAN ELAN Frame Check Sequence...
  • Page 73 Quality of Service Service Data Unit SSIM SmartStack Interface Module SSCOP Service Specific Connection Oriented Protocol Spanning Tree Explorer Switched Virtual Circuit User Network Interface Virtual ATM Port Virtual Channel Connection Virtual Channel Identifier Virtual Path Identifier SmartStack SSIM-A2-01/SSIM-A8-01...

  • Page 74: Appendix B. Log Messages

    Appendix B. Log Messages Error messages that can appear on the console screen are listed below. Following each message is a short explanation of the message and, where appropriate, steps that can be taken to resolve the error condition. 0001 Lan Emulation Server join timeout - Retrying! The LAN Emulation Server did not answer of our JOIN request.
  • Page 75 0006 Lan Emulation Server connection failed. The connection between the LAN Emulation Client and the LAN Emulation Server was lost. Action: Check that the LES is running and that the cable to switch is connected. 0007 Lan Emulation Server BUS ARP failed. <xx> The LAN Emulation Client got a bad response from the Broadcast and Unknown Server (BUS).
  • Page 76 Action: Check the configuration of the BUS and/or Increase the JoinTimeout value in the configuration file. 000F Lan Emulation Config Value out of range, TLV-type: <xx>, Value: <xxxx> A TLV (Type Length Value) encoded parameter from the LAN Emulation Configuration Server (LECS) was either not supported or not within the range supported by the LAN Emulation client.
  • Page 77 Call setup cleared by network or remote user. Link is not active (being started). Call failed because protocol is being reset (by user). 4A Link failure (during call setup). Remote user signaling state mismatch. Received message from remote user with protocol error. 4D Temporary out of local signaling resources.
  • Page 78 Bearer capability not implemented Unsupported combination of traffic parameters AAL parameters cannot be supported Invalid call reference value Identified channel does not exist Incompatible destination Invalid endpoint reference Invalid transit network selection Too many pending add parties requests AAL parameters cannot be supported Mandatory information element is missing Message type non-existent or not implemented Information element non-existent or not implemented...
  • Page 79 0206 Outg. call rejected by network: <Called ATM address> <Location Code>:<Cause Code> As for '0204', but where the call is rejected by the 'ATM network', as coded by the 'location' field: The location code is normally 1, but may also be one of the following: Local Private Network Local Public Network Transit Network...
  • Page 80 BGAK PDU BGREJ PDU END PDU ENDAK PDU POLL PDU STAT PDU USTAT PDU RS PDU RSAK PDU ER PDU (not if UNI 3.0) ERAK PDU (not if UNI 3.0) Action: Check configuration. Does the configured UniVersion match the one supported by the ATM switch? If not, fix it.
  • Page 81 Action: The physical link may be poor - check it. 0406 SSCOP: STAT PDU - N(R) or list elements error A STAT PDU has been received, either containing an unexpected value in the N(R) field, or containing an error in list elements. Link recovery is being performed and Signalling protocol is notified.
  • Page 82 0504 CRC checksum failure on adapter Eeprom. This message indicates a hardware error with the ATM Uplink. Action: Replace ATM Uplink card. 0505 SAR memory self-test failed during open. This message indicates a hardware error with the ATM Uplink. Action: Replace ATM Uplink card. 0601 Registered Prefix did not match configuration.
  • Page 83 Action: Check compatibility of clients and LAN Emulation services participating in emulated LAN. 0707 ILMI: Prefix Registration time-out, Cold Start retried. Time-out of Prefix registration from switch. Address registration procedure is restarted by re-sending Cold Start trap. Action: Informative message, see also code 602. 0708 ILMI: Get Response time-out, Get Request retried.
  • Page 84 Action: Remove or correct PVC definition. 0807 PVC User Index too large. The UserIndex parameter of a PVC definition for the Lan Emulation Server identifies a specific client and must have a value from 1 to MaxClients (default 50). Action: Adjust MaxClients or correct PVC configuration. 0808 PVC ATM address is wrong <xx>...
  • Page 85 0826 PVC VCI value too large. VPI=<xx>, VCI=<yy>, Max VPI=<zz> The VCI value for the PVC <xx>:<yy> is too large, the maximum VCI value is <zz>. Action: Change the VCI value to a smaller value or enable usage of larger VCI values by increasing the MaxVciBits value.
  • Page 86 index-1 Index abbreviations LAN emulation client ATM configuration - port xx menu LAN emulation configuration server ATM ELAN configuration screen LANE parameters ATM network advanced parameters screen LANE parameters screen ATM network configuration screen LANE status screen ATM network parameters LE-ARP table screen LEC See LAN emulation client LECS See LAN emulation configuration server...
  • Page 87 index-2 using the menus UTP5 cabling VAP See virtual ATM port VCC statistics screen virtual ATM port VT100 console SmartStack SSIM-A2-01/SSIM-A8-01 Index...
  • Page 88 * 710001815*...
