ATM LEC Main Configuration Screen

To view and edit the ATM LEC setup, select ATM LEC Setup from the ATM
Configuration menu. If there are multiple VAPs, you will be prompted for the
VAP you want to configure. The VAP name is shown in the title bar.
Enabled
Sets the administrative state of the Virtual ATM Port (VAP) connecting the CRF
to the ELAN. Possible values are Yes and No.
Status
The following table shows the current status information of the VAP.
Value
Admin Down
Going Admin Down
Waiting for
Module Up
Going Up
Table 6. Current Status Information of the VAP
SmartStack SSIM-A2-01/SSIM-A8-01
The VAP is disabled
The VAP is changing to the Admin Down State
The VAP is waiting for the port to come up. The
port may be administratively disabled
The VAP is waiting for the port to come up or is
trying to connect to LAN Emulation Services
Meaning
Console Configuration
