T316
The maximum time to wait for response to RESTART.
Possible values: 1 to 255.
Default: 120.
T317
The maximum time to act on RESTART. The value set should be less than T316.
Possible values: 1 to 255.
Default: 60.
T322
The maximum time to wait for response to STATUS ENQUIRY.
Possible values: 1 to 255.
Default: 4.
These values correspond to the standard values used on ordinary Token-Ring ports.
Actually, slightly larger frame sizes are allowed to accommodate the frame sizes
defined by the ATM Forum LAN Emulation standard.
The following table shows the configured and actual frame size, as well as the
corresponding largest frame size bits that are used in explorer RIF expansion:
MTU
Configured
1500
4472
8144
17800
Table 5. Configured and Actual Frame Size
SmartStack SSIM-A2-01/SSIM-A8-01
TR-LANE
Max Data
frame size
1516 001
4544 011
9234 100
18190 110
LF bits
25
Console Configuration
