Software Installation
Before you can use your SSIM-Ax-01 module, you must install the uplink module
software. The module software can be downloaded via TFTP or via a serial line.
Search the disks supplied with the module for a file named ATMyzv.bin. The letters
yzv in the file name represent the version number of the software. For example,
ATM400.bin is version 4.00 of the module software.
TFTP Download
1. Copy the software image to a suitable directory on the TFTP server.
2. From the Main menu in the console, select Download
Download
3. Select TFTP Download
will be displayed.
4. On this menu, set the IP address of the TFTP server. Also, set the download
VLAN (the BRF on which the TFTP server is located).
5. Select ATM Firmware Download. The ATM Firmware TFTP Download
screen is displayed.
6. Select ATM Firmware Download Filename and type the filename of the
software image to download.
7. Select Execute ATM Image Network Download to start the download.
SmartStack SSIM-A2-01/SSIM-A8-01
Upload menu will be displayed.
Upload. The TFTP Download
Upload. The
Upload menu
Installation
9
